CRYORIG R1 Universal 140mm Dual Tower CPU Cooler

$89.99
CRYORIG R1 Universal 140mm Dual Tower CPU Cooler SKU: FN0631

$89.99

Ready to Ship!
Check Store Stock

Huntsville Store:

Las Vegas:

CRYORIG R1 UNIVERSAL

Performance with Compatibility
Designed for Perfection
The Limitless Universal Cooler

Full Contact
Enhanced Performance


Patented DirectCompress™ Soldering, increases the actual contact surface between the heatpipe and heatsink fins. DirectCompress™ Soldering has up to 10% more contact surface compared to traditional soldering, and the more contact surface the faster the heat conduction.

Spreading Out
and Making Room


On aluminum sheets, heat spreads out in a radial direction. By displacing the heatpipe alignment on the heatsink fins, our Heatsink Displacement Optimization™ allows for better and more evenly spread heat conduction on the fins compared to traditional linear alignment.

Full Contact
Enhanced Performance


Patented DirectCompress™ Soldering, increases the actual contact surface between the heatpipe and heatsink fins. DirectCompress™ Soldering has up to 10% more contact surface compared to traditional soldering, and the more contact surface the faster the heat conduction.

Spreading Out
and Making Room


On aluminum sheets, heat spreads out in a radial direction. By displacing the heatpipe alignment on the heatsink fins, our Heatsink Displacement Optimization™ allows for better and more evenly spread heat conduction on the fins compared to traditional linear alignment.

Accelerated Air Exhaust
The Faster the Cooler


The individual tower stack is separated into two sections, the loose air intake and the high density exhaust section. By the laws of fluid dynamics, the increase in fin count in the exhaust section squeezes airflow and increases exhaust air speed. The increase of airflow speed in our Jet Fin Acceleration System™ allows heated air leave the tower faster.

Optimized
Heatpipe Positioning
Total CPU Coverage


The R1’s Heatpipe Convex-Align™ System allows for more heatpipes in a given area, optimized heatpipe placement in the copper base, and improved alignment with your CPU. With the Heatpipe Convex-Align™ System, each heatpipe functions to their maximum TDP capacity.

Kill the Noise
Silence is Cold


Acoustics are just as important as performance. That’s why both the XF140 and XT140 140mm fan integrate acoustic optimizations. Both fans featuring High Precision Low Noise (HPLN™) bearing and the detachable Acoustic Vibration Absorbers that give the fan a snugger fit while canceling vibration and noise at the same time.

Unmatched Compatibility
Zero RAM Interference


Focusing on providing the widest range of compatibility, the R1 utilizes an asymmetric slanted heatpipe layout to move the front heatsink fin stack further away from the RAM zone. Also, fitted with a 13mm thin XT140 the CRYORIG R1 offers optimal compatibility for RAM with tall heat spreaders on both Intel™ (115X/1366/775) and AMD platforms.

Patent Pending
"MultiSeg™"
Quick Mount System


Patent Pending "Multiseg™" Quick Mount System providing an all in one solution on Intel™ platforms, CRYORIG’s MultiSeg™ Quick Mount System allows for a securer and firmer installation within minutes.

Customization Capable
With CUSTOMOD Covers


The fan covers for R1 is fully modular and replaceable with CRYORIG’s CUSTOMOD Covers. Available in all the major mainboard color schemes, choose your color based on your system’s general color scheme, or match together all your favorite colors. It’s your PC, why not make it personal! (CUSTOMOD Covers for R1 sold separately.)

HEATSINK SPECIFICATION
Dimension ( with fan ) L128.5 mm x W140 mm x H168.3 mm
Weight ( with fan ) 1215 g
Weight ( without fan ) 970 g
Heat pipes 6mm heatpipe x 7 units
Front Fin T = 0.4 mm ; Gap = 2.4 mm
Front Fin Pcs 42 pcs
Rear Fin T = 0.4 mm ; Gap = 1.8 mm
Rear Fin Pcs 53 pcs
Copper Base C1100 Pure copper nickel plated
Distance From Center 35.5 mm
RAM Height Limit Limitless
TDP 240 W+
XF140 SPECIFICATION
Dimension L140 mm x W140 mm x H25.4 mm
Weight 156 g
Rated Speed 700 ~ 1300 RPM ±10 %
Noise Level 19 ~ 23 dBA
Air Flow 76 CFM
Air Pressure 1.44 mmH2O
Ampere 0.16 A
XT140 SPECIFICATION
Dimension L140 mm x W140 mm x H13 mm
Weight 89 g
Rated Speed 700 ~ 1300 RPM ±10 %
Noise Level 20 ~ 24 dBA
Air Flow 65 CFM
Air Pressure 1.49 mmH2O
Ampere 0.27 A
