80 PLUS Gold certified, with 90% (115VAC) / 92% (220VAC~240VAC) efficiency or higher under typical loads
Fully Modular to reduce clutter and improve airflow
Unbeatable EVGA 7 Year Warranty and unparalleled EVGA Customer Support.
100% Japanese Capacitors ensure long-term reliability
Fluid Dynamic Bearing Fan for ultra-quiet operation and increased lifespan.
Auto ECO Mode to ensure silent operation under low to medium loads with no configuration necessary
Heavy-duty protections, including OVP (Over Voltage Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), OPP (Over Power Protection), SCP (Short Circuit Protection), and Dual OTP (Over Temperature Protection)
CABLE LENGTH:
ATX Cable           1x 600mm (m)
EPS Cable           2x 700mm (m)
PCIe Cable          2x 700mm, 850mm (m)
SATA Cable        2x 550mm, 650mm, 750mm (m)
Four-Pin Peripheral Cable            1x 550mm, 650mm, 750mm (m)
Floppy Adapter 1x Molex to FDD Adapter
AC Power           1x 1500mm (m)
Modular Cable Type       Full
Molex to FDDÂ Â Â Â 1x
Â
CONNECTOR QUANTITY:
24 Pin ATXÂ Â Â Â Â Â Â Â Â Â 1x
EPS (CPU)Â Â Â Â Â Â Â Â Â Â Â 2x 8pin(4+4)
PCIe      4x 8pin(6+2)
SATAÂ Â Â Â 6x
Four-Pin Peripheral        3x
Floppy 1x
Â
POWER SPECS:
AC Input             100-240V~, 10-5A, 60/50 Hz
Rail        +3.3V   +5V       +12V     +5Vsb  -12V
Max Output       20A       20A       62.5A    3A          0.3A
130WÂ Â Â Â 750WÂ Â Â Â 15WÂ Â Â Â Â Â 3.6W
Total     750W@50°C
Â
ADDITIONAL DETAILS:
Operating Temperature 0° to 50° C
Japanese Capacitors      100%
ECO Mode         Auto
MTBFÂ Â Â 100,000 Hours
Net Weight        6 lbs
Size       86mm (H) x 150mm (W) x 150mm (L)
Approvals           TUV, CB, CE, FCC, RCM, cTUVus, BSMI, CCC, WEEE, RoHS, Compliance with ErP Lot 3 2014 Requirement
Fan Size / Bearing            135mm Fluid Dynamic Bearing
MFG P/N: 220-GT-0750-Y1
UPC CODE: 843368060541
