Lens Configuration: 14 elements in 10 groups (includes 3 aspherical and 1 ED elements)
Focal Length: 18-55mm
35mm Equivalent Focal Length: 27-84mm
Angle of View: 76.5-29
Maximum Aperture: F2.8-F4
Minimum Aperture: F22
Number of Aperture Blades: 7 (rounded diaphragm opening)
Aperture Step Size: 1/3EV (19 steps)
Minimum Focusing Distance (cm): 30
Minimum Focusing Distance (in): 11.81
Minimum Focusing Distance - Telephoto (cm): 40
Minimum Focusing Distance - Telephoto (in): 15.75
Maximum Magnification: 0.15x (Telephoto)
Lens Diameter (mm): 65
Lens Length (mm): 70.4
Lens Length (in): 2.77
Lens Length - Extended (mm): 97.9
Lens Length - Extended (in): 3.85
Lens Weight (g): 310
Lens Weight (lb): 0.68
Filter Size: 58mm
Number of Effective Pixels: 40.2 millions pixels
Image Sensor: 23.5mm x 15.6mm (APS-C) X-Trans CMOS 5 HR with primary color filter
Sensor Cleaning System: Ultra Sonic Vibration
Storage Media: SD Card (-2GB) / SDHC Card (-32GB) / SDXC Card (-2TB) / UHS-I / UHS-II / Video Speed Class V90 / CFexpress Type B Card (-2TB) *Please visit https://fujifilm-x.com/support/compatibility/cameras to check memory card compatibility.
File format (Still): JPEG-Exif Ver.2.32, HEIF-4:2:2 10bit, RAW-14bit RAW (RAF original format), TIFF-8bit / 16bit RGB (In-camera Raw Conversion Only)
*Exif 2.32 is a digital camera file format that contains a variety of shooting information for optimal printing
Number of Recorded Pixels
- L: [3:2] 7728 x 5152 [16:9] 7728 x 4344 [1:1] 5152 x 5152
- M: [3:2] 5472 x 3648 [16:9] 5472 x 3080 [1:1] 3648 x 3648S: [3:2] 3888 x 2592 [16:9] 3888 x 2184[1:1] 2592 x 2592
Digital Tele-Converter: 2.0x,1.4x,OFF
Lens Mount: FUJIFILM X mount
Sensitivity Standard Output
- Still: AUTO1/ AUTO2/ AUTO3/ ISO12512800 (1/3 step)
- Movie: AUTO/ ISO12512800 (1/3 step)
Sensitivity Extended Output
- Still: ISO80/I SO100/ ISO25600/ ISO51200
- Movie: ISO25600
Exposure Control: TTL 256-zone metering/ Multi/ Spot/Average/ Center Weighted
Exposure Mode: P (Program AE)/ A (Aperture Priority AE)/ S (Shutter Speed Priority AE)/ M (Manual Exposure)
Exposure Compensation: Still: -5.0EV+5.0EV (1/3EV step)/ MOVIE: -2.0EV+2.0EV (1/3EV step)
Image Stabilizer Mechanism: Image sensor shift mechanism with 5-axis compensation
Image Stabilizer Compensation Effect: Up to 7.0 stops (based on CIPA standard). Pitch/yaw shake only, with XF35mmF1.4 R lens attached.
Image Stabilizer Digital Image Stabilization: Yes, movie mode only
Image Stabilizer IS MODE BOOST: Yes, movie mode only
Shutter Type: Focal Plane Shutter
Shutter Speed Mechanical Shutter
- P mode: 30 sec to 1/8000
- A mode: 30sec to 1/8000
- S/M mode: 15min to 1/8000
- Bulb mode: up to 60min
Shutter Speed Electronic Shutter
- P mode: 30 sec to 1/80000
- A mode: 30sec to 1/80000
- S/M mode: 15min to 1/80000
- Bulb mode: 1sec Fixed
Shutter Speed Electronic Front curtain Shutter
- P mode: 30 sec to 1/8000
- A mode: 30sec to 1/8000
- S/M mode: 15min to 1/8000
- Bulb mode: up to 60min
Shutter Speed Mechanical + Electronic Shutter
- P mode: 30 sec to 1/80000
- A mode: 30sec to 1/80000
- S/M mode: 15min to 1/80000
- Bulb mode: up to 60min
*Mechanical shutter works until 1/8000sec.
Shutter Speed E-Front + Mechanical Shutter
- P mode: 30 sec to 1/8000
- A mode: 30sec to 1/8000
- S/M mode: 15min to 1/8000
- Bulb mode: up to 60min
- E116
*Electronic front curtain shutter works until 1/2000sec.
Shutter Speed E-Front + Mechanical + Electronic Shutter
- P mode: 30 sec to 1/80000
- A mode: 30sec to 1/80000
- S/M mode: 15min to 1/80000
- Bulb mode: 1sec Fixed. *Electronic front curtain shutter works until 1/2000sec, Mechanical shutter works until 1/8000sec. *The Electronic Shutter may not be suitable for fast-moving objects or handheld shooting. Flash can not be used.
Shutter Speed Movie
- 6.2K: 1/8000 to 1/24
- DCI 4K/4K: 1/8000 to 1/4 sec.
- FHD: 1/8000 to 1/4 sec.
Synchronized Shutter Speed for Flash
- Mechanical Shutter: 1/250sec. or slower
- Electronic Shutter: 1/125sec. or slower
Continuous Shooting
- Electronic Shutter Approx. 20fps (1.29x Crop) (JPEG: 168 frames ,Compressed RAW: 72, Lossless
- Compressed RAW 41, Uncompressed RAW: 37 frames, Uncompressed RAW + JPEG: 23 frames)
- Electronic Shutter Approx. 13fps (1.29x Crop) (JPEG: 1000+ frames ,Compressed RAW: 104, Lossless
- Compressed RAW: 53, Uncompressed RAW: 23 frames, Compressed RAW + JPEG: 56, Lossless compressed RAW + JPEG: 44, Uncompressed RAW + JPEG: 23)
- Electronic Shutter Approx. 10fps (1.29x Crop) (JPEG: 1000+ frames ,Compressed RAW: 1000+, Lossless
- Compressed RAW 70, Uncompressed RAW: 25 frames, Compressed RAW + JPEG: 72 frames, Lossless compressed RAW + JPEG: 53 frames, Uncompressed RAW + JPEG: 23 frames)
- Mechanical Shutter Approx. 15fps (JPEG: 119frames ,Compressed RAW: 39 frames, Lossless Compressed
- RAW 22 frames, Uncompressed RAW: 19 frames, Compressed RAW + JPEG 27 frames)
- Mechanical Shutter Approx. 10fps (JPEG: 1000+ frames ,Compressed RAW: 56 frames, Lossless
- Compressed RAW 29 frames, Uncompressed RAW: 19 frames, Compressed RAW + JPEG: 34 frames)
- Mechanical Shutter Approx. 7.0fps (JPEG: 1000+ frames ,Compressed RAW: 1000+ frames, Lossless
- Compressed RAW 33 frames, Uncompressed RAW: 20 frames, Compressed RAW + JPEG: 45 frames,
- Lossless compressed RAW + JPEG: 22 frames, Uncompressed RAW + JPEG: 20 frames)
- Electronic Shutter Approx. 20fps (1.29x Crop) (While half press 20 frames ,After full press 140 frames)
- Electronic Shutter Approx. 13fps (1.29x Crop) (While half press 13 frames ,After full press 300 frames,)
- Electronic Shutter Approx. 10fps (1.29x Crop) (While half press 10 frames ,After full press 370 frames,)
- Electronic Shutter Approx. 13fps (While half press 13 frames ,After full press 70 frames,)
*Recordable frames depends on recording media
*Speed of continuous shooting depends on shooting environment and shooting frames
AE Bracketing
- AE Bracketing (Frames: 2, 3, 5, 7, 9 Step: by 1/3EV step, up to 3EV steps)
- Film simulation bracketing (Any 3 types of film simulation selectable)
- Dynamic Range Bracketing (100%, 200%, 400%)
Focus Mode: Single AF/ Continuous AF/ MF
Focus Type: Intelligent Hybrid AF (TTL contrast AF / TTL phase detection AF)
Focus Low-light Performance
- Contrast: -4.0EV
- Phase Detection: -7.0EV
- *XF50mmF1.0 attached
AF Frame Selection
- Single point AF: 139/ 2517 (Changeable size of AF frame)
- Zone AF: 33/ 55/ 77 from 117 areas on 139 grid
- Wide/Tracking AF AF-S: Wide/ AF-C: Tracking
- All
White Balance: Auto (WHITE PRIORITY, AUTO, AMBIENCE PRIORITY)/ Custom1 - 3/ Color temperature selection (2500K10000K)/ Preset Daylight, Shade, Fluorescent Light-1, Fluorescent Light-2, Fluorescent Light-3, Incandescent Light, Underwater
Self-timer: 10sec./2sec.
Interval Timer Shooting: Yes (Setting : Interval, Number of shots, Starting time, Interval timer shooting exposure smoothing)
Flash: EF-X8 Guide Number approx. 11 (ISO200m) / approx. 8 (ISO100m)
Flash Sync Mode: EF-X8: 1st Curtain/ 2nd Curtain
Shoe Mount Flash: 1st Curtain/ 2nd Curtain AUTO FP (HSS)
Synchronized terminal: 1st Curtain/ 2nd Curtain.
Flash Mode: TTL (TTL AUTO / STANDARD / SLOW SYNC. ) / MANUAL / COMMANDER / OFF Shoe Mount Flash TTL (TTL AUTO) / STANDARD / SLOW SYNC. ) / MANUAL / MULTI
* When EF-X500 is set/ OFF Synchronized terminal MANUAL
Hot Shoe: Yes (Dedicated TTL Flash compatible)
Viewfinder EVF
- 0.5 inch approx. 3.69 million dots OLED Color Viewfinder
- Coverage of viewing area vs. capturing area: approx. 100%
- Eyepoint: approx. 24mm (from the Rear End of the camera's Eyepiece) Diopter adjustment: -5~+3m-1
- Magnification: 0.80 with 50mm lens (35mm equivalent) at infinity and Diopter set to -1.0m-1
- Diagonal angle of view: approx. 40 (Horizontal angle of view: approx. 32 ) Built-in eye sensor
LCD Monitor
- 3.0 inch Tilt-Type (Three Direction) Touch Screen Color LCD Monitor
- Aspect Ratio 3:2
- Resolution Approx. 1.84 million dots
Touch Screen Shooting Mode: Shooting, AF, Focus Area, OFF, Double Tap Setting (ON/OFF), Touch Function Setting (ON/OFF), EVF Touch Screen Area Setting
Touch Screen Playback Mode: Swipe, Pinch-in / Pinch-out, Double-tap, Drag
- HEVC/ H.265
- Audio: Linear PCM / Stereo sound (24bit / 48KHz sampling)
- MPEG-4, AVC/ H.264
- Audio: Linear PCM / Stereo sound (24bit / 48KHz sampling)
- MP4, MPEG-4, AVC/ H.264
- Audio: AAC
Movie Compression: All Intra/Long-GOP
File Size / Frame Rate / Recording Time
- 6.2K [16:9] - 62403150
29.97p/ 25p/ 24p/ 23.98p
360Mbps/ 200Mbps/ 100Mbps/ 50Mbps
- DCI 4K [17:9] - 40962160
59.94p/ 50p/ 29.97p/ 25p/ 24p/ 23.98p
360Mbps/ 200Mbps/100Mbps/50Mbps
- 4K [16:9] - 38402160
59.94p/ 50p/ 29.97p/ 25p/ 24p/ 23.98p
720Mbps/ 360Mbps/ 200Mbps/ 100Mbps/ 50Mbps
- Full HD [17:9] -20481080
59.94p/ 50p/ 29.97p/ 25p/ 24p/ 23.98p
360Mbps/ 200Mbps/ 100Mbps/ 50Mbps
- Full HD [16:9] - 19201080
59.94p/ 50p/ 29.97p/ 25p/ 24p/ 23.98p
360Mbps/ 200Mbps/ 100Mbps/ 50Mbps
- Full HD High speed rec. [17:9] - 2048x1080
240p/200p/ 120p/ 100p
360Mbps(recording)/ 200Mbps(recording)
- Full HD High speed rec. [16:9] - 1920x1080
240p/200p/ 120p/ 100p/
360Mbps(recording)/ 200Mbps(recording)
*For recording movies, use a SD memory card with UHS Speed Class 3 or higher.
*For recording movies in 360Mbps, use a SD memory card with Video Speed Class 60 or higher.
*Selectable bitrate will be changed depends on the setting.
*Recording length can shorten depending on the temperature and/or shooting conditions
Film Simulation Mode: 19 modes (PROVIA/Standard, Velvia/Vivid, ASTIA/Soft, Classic Chrome, PRO Neg.Hi, PRO Neg.Std, Classic Neg., Nostalgic Neg., ETERNA Cinema, ETERNA BLEACH BYPASS, ACROS, ACROS + Ye Filter, ACROS + R Filter
ACROS + G Filter, Black & White, Black & White + Ye Filter, Black & White + R Filter, Black & White + G Filter, Sepia)
Clarity setting: 5 steps
Monochromatic Color: Yes
Grain Effect: Roughness STRONG, WEAK, OFF, Size LARGE, SMALL
Color Chrome Effect: STRONG, WEAK, OFF
Color chrome Blue: STRONG, WEAK, OFF
Smooth Skin Effect: STRONG, WEAK, OFF
Dynamic Range Setting
- AUTO, 100%, 200%, 400%
- ISO restriction (DR100%: No limit, DR200%: ISO320 or more, DR400%: ISO640 or more)
Dynamic Range Setting (Movie)
- 100%, 200%, 400%
- ISO restriction (DR100%: No limit, DR200%: ISO320 or more, DR400%: ISO640 or more)
Advanced Filter
- Toy camera
- Miniature
- Pop color
- High-key
- Low-key
- Dynamic tone
- Soft focus
- Partial color (Red / Orange / Yellow / Green / Blue / Purple)
Wireless Transmitter Standard: IEEE802.11a/b/g/n/ac (standard wireless protocol)
Wireless Transmitter Encryption: WEP/WPA/WPA2 mixed mode
Wireless Transmitter Access Mode: Infrastructure
Terminal - Digital Interface: USB Type-C (USB3.2 Gen2x1)
Terminal - HDMI Output: HDMI connector (Type D)
Terminal - Others: 3.5mm, stereo mini connector (Microphone), 2.5mm, Remote Release Connector, Hot shoe, Synchronized terminal
Power Supply: NP-W235 Li-ion battery (included)
Battery Life for Still Images: Economy Mode Approx. 740 frames, Normal Mode Approx. 580 frames
*When XF35mmF1.4 R is set
Actual Battery Life for Movie Capture
- 6.2K Approx. 90min. (29.97p)
- 4K Approx. 80min. (59.94p)
- Full HD Approx. 90min. (59.94p)
- Full HD Approx. 100min. (120P)
Continuance Battery Life for Movie Capture
- 6.2K Approx. 130min. (29.97p)
- 4K Approx. 130min. (59.94p)
- Full HD Approx. 150min. (59.94p)
Approximate External Camera Dimensions: (W) 129.5mm x (H) 91mm x (D) 63.8mm - Minimum Depth 37.9mm
Approximate External Lens Dimensions: 65mm x 70.4mm (Wide)/ 97.9mm (Telephoto)
Camera Width (mm): 129.5
Camera Height (mm): 91
Camera Depth (mm): 63.8
Camera Minimum Depth (mm): 37.9
Camera Width (in): 5.09
Camera Height (in): 3.58
Camera Depth (in): 2.51
Camera Minimum Depth (in): 1.49
Camera Body Weight: Approx. 557g including battery and memory card, Approx. 476g excluding battery and SD memory card
Operating Temperature: -10C-40C/ 14F-104F
Operating Humidity: 10% - 80% (no condensation)
Start Up Period: Approx. 0.49sec.
- FLCP-58 II Lens cap
- RLCP-001 Rear lens cap
- Lens hood
- Li-ion battery NP-W235S
- AC power adapter AC-5VJ
- Plug adapter
- USB cable
- Headphone Adapter
- Shoulder strap
- Body cap
- Hot shoe cover
- Sync terminal cover
