Processor & Chipset
Chipset Manufacturer: Intel
Chipset Model: Z790
Total Processor Supported: 1
Processor Socket: Socket LGA-1700
Processor Generation Supported: 13th Gen
Processor Generation Supported: 12th Gen
Processor Supported: Pentium Gold
Processor Supported: Celeron
Processor Supported: Core
Multi GPU Supported: CrossFire
Memory
Number of Memory Slots: 4
Memory Form Factor: DIMM
Memory Form Factor: UDIMM
Maximum Memory Supported: 128 GB
Memory Technology: DDR5 SDRAM
I/O Expansions
Number of Total Expansion Slots: 6
PCI Express Standard: PCI Express 3.0
PCI Express Standard: PCI Express 4.0
PCI Express Standard: PCI Express 5.0
Total Number of PCI Express Slots: 6
Number of PCI Express x1 Slots: 2
Number of PCI Express x16 Slots: 4
Interfaces/Ports
Total Number of USB Ports: 10
Number of USB 2.0 Ports: 4
Number of USB 3.2 Gen 1 Ports: 4
Number of USB 3.2 Gen 2 Type-A Ports: 1
S/PDIF: Yes
HDMI: Yes
Number of Network (RJ-45) Ports: 1
Onboard Interfaces
Number of SATA Interfaces: 6
Number of M.2 Interfaces: 3
Total Number of Onboard USB Ports: 7
Number of Onboard USB 2.0 Ports: 4
Physical Characteristics
Form Factor: ATX
Width: 12"
Depth: 9.6"
