Messi & Paoloni HyperFlex 13 PL-259s 9ft
Messi & Paoloni HyperFlex 13 PL-259s 9ft
The Messi & Paoloni Hyperflex 13 Cable offers a variety of features that make it an excellent choice for your needs. Here are some reasons why you should choose it:
- Lightweight, compact, and extremely flexible design allows for easy handling and installation.
- Double shielded with bare Copper Clad Al braid over copper foil, ensuring no Galvanic current effect.
- The cable is optimized for amazing flexibility, with every layer of the cable designed for the best result.
Even surface of the 37 wires core provides excellent performances for attenuations and power handling. - Top-level performances in the stranded core class of cables, even compared to bigger .600" cables.
- Improved Foam Pe structure and resistance to multiple bends (under reasonable angles) and moisture.
- Outstanding velocity ratio (86%) and screening efficiency (SA>105 dB), ensuring great signal quality.
- Enhanced structure in the braiding process (50% more Crossovers) giving the braid an active role in the resistance to torsions, typical of cables linked to rotor operated antennas.
- Engineered to provide the best attenuation performance and flexibility in a compact size cable, sitting right in between the .400" cables (like RG213/U and LMR400) and the .600" cables.
- The cable is matched with M&P Original connectors, and the power handling values in M&P cables are for RTTY transmissions. For SSB, you can double the values.
- It is important to note that you should never exceed the indicated peak power value to ensure the best performance and longevity of the cable.
HyperFlex 13, PL-259s, 9ft has a high-resistance copper-clad aluminum screen made by means of a 24-spool braiding machine, generating 50% more crossovers compared to traditional 16 spool machines. This braid is highly effective against low-frequency impulsive noises, with a screening potential of 70%. %. It also has a high pressure physical injection foam polyethylene triple layer dielectric. The inner conductor is made of thirty-seven .56mm stranded geometric and concentric annealed 99.99% pure copper wires. The copper foil has an applied PE-coating, placed in order to prevent foil cracking due to short-radius bends, with a screening potential of 100%. The UV-resistant PVC jacket is extra flexible.
HyperFlex 13, PL-259s 9ft has a high-resistance copper-clad aluminum screen made by means of a 24-spool braiding machine, generating 50% more crossovers compared to traditional 16 spool machines. This braid is highly effective against low-frequency impulsive noises, with a screening potential of 70%. %. It also has a high pressure physical injection foam polyethylene triple layer dielectric. The inner conductor is made of thirty-seven .56mm stranded geometric and concentric annealed 99.99% pure copper wires. The copper foil has an applied PE-coating, placed in order to prevent foil cracking due to short-radius bends, with a screening potential of 100%. The UV-resistant PVC jacket is extra flexible.
