Intel BX80658I75775C
Intel Core i7-5775C 3.30GHz 4C/8T 6MB Iris Pro 6200 Graphics 37W
With previous generation Intel® Core™ i7 processors access multiple applications faster and unleash incredible digital media creation. Experience great performance for everything you do with the combination of Intel® Turbo Boost Technology and Intel® Hyper-Threading Technology (Intel® HT Technology), which maximizes performance to match your workload.
Essentials
Launch Date: Q2'15
Processor Number: i7-5775C
Cache: 6 MB
DMI2: 6.4 GT/s
# of QPI Links: 0
Instruction Set: 64-bit
Instruction Set Extensions: SSE 4.1/4.2 AVX 2.0
Embedded Options Available: No
Lithography: 14 nm
Scalability: 1S Only
Thermal Solution Specification: PCA 2013D
Performance
# of Cores: 4
# of Threads: 8
Processor Base Frequency: 3.3 GHz
Max Turbo Frequency: 3.7 GHz
TDP: 65 W
Memory Specifications
Max Memory Size (dependent on memory type): 32 GB
Memory Types: DDR3L 1333/1600
Max # of Memory Channels: 2
Max Memory Bandwidth: 25.6 GB/s
ECC Memory Supported ‡: No
Graphics Specifications
Processor Graphics ‡: Intel® Iris™ Pro Graphics 6200
Graphics Base Frequency: 300 MHz
Graphics Max Dynamic Frequency: 1.15 GHz
Graphics Video Max Memory: 1.7 GB
Graphics Output: DP/HDMI/VGA
Execution Units: 48
Max Resolution (HDMI): [email protected]
Max Resolution (DP): [email protected]
DirectX* Support: 11.2
OpenGL* Support: 4.3
Intel® Quick Sync Video: Yes
Intel® InTru™ 3D Technology: Yes
Intel® Insider™: Yes
Intel® Wireless Display: Yes
Intel® Flexible Display Interface (Intel® FDI): Yes
Intel® Clear Video HD Technology: Yes
Intel® Clear Video Technology: Yes
# of Displays Supported ‡: 3
Device ID: 1622
Expansion Options
PCI Express Revision: 3.0
PCI Express Configurations ‡: Up to 1x16 2x8 1x8 + 2x4
Max # of PCI Express Lanes: 16
Package Specifications
Max CPU Configuration: 1
Package Size: 37.5mm x 37.5mm
Graphics and IMC Lithography: 14 nm
Sockets Supported: FCLGA1150
Low Halogen Options Available: See MDDS
Advanced Technologies
Intel® Turbo Boost Technology ‡: 2.0
Intel® vPro Technology ‡: No
Intel® Hyper-Threading Technology ‡: Yes
Intel® Virtualization Technology (VT-x) ‡: Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡: Yes
Intel® VT-x with Extended Page Tables (EPT) ‡: Yes
Intel® TSX-NI: Yes
Intel® 64 ‡: Yes
4G WiMAX Wireless Technology: No
Idle States: Yes
Enhanced Intel SpeedStep® Technology: Yes
Thermal Monitoring Technologies: Yes
Intel® Virtualization Technology for Itanium (VT-i): No
Intel® Stable Image Platform Program (SIPP): No
Intel® Small Business Advantage: No
Intel® Data Protection Technology
AES New Instructions: Yes
Secure Key: Yes
Intel® Platform Protection Technology
OS Guard: Yes
Trusted Execution Technology ‡: No
Execute Disable Bit ‡: Yes
Anti-Theft Technology: Yes
