PoE Module 5V for Arduino
The Ag9120-S is a module designed to extract power from a conventional twisted pair Category 5 Ethernet cable, conforming to the IEEE 802.3af Power-over-Ethernet (PoE) standard.
The Ag9120-S provides the PoE compatibility signature and power classification required by the Power Sourcing Equipment (PSE) before applying up to 15W power to the port.
The high efficiency DC/DC converter operates over a wide input voltage range (36V to 48V typ) and provides a regulated low ripple and low noise output. The DC/DC converter also has built-in overload and short-circuit output protection.
Features:
  • IEEE802.3af compliant
  • Small SIL package size - 56mm (L) x 14mm (H)
  • Low output ripple and noise
  • Input voltage range 36V to 57V
  • Overload and short-circuit protection
  • High efficiency DC/DC converter (75% typ)
  • 1500V isolation (input to output)
