Radiowavz RWSTMB206B

Radiowavz Sentinel Hexagonal Beam 6 band (20m - 6m)
Do you want to upgrade your Sentinel Hex beam to have a power rating of 3.5kw SSB PEP/ 1500w CW? Upgrade for $350 to have Radiowavz add 12g wire to your antenna, please notify your customer care specialist.  .


Features

• Low SWR
• No tuning required, just plug and play
• Improved broad band response over original hex beam design
• Performs well at lower heights
• Handles full legal limit of power
• Small physical foot print, 33% smaller than a full sized beam.

Specifications

• Operates on 20m, 17m, 15m, 12m, 10m, and 6m
• Gain Peak Approx 5.5 dBi
• Front/Back Peak > 20dB
• VSWR Less than 2:1 across nearly all bands
• Turn Radius 11 Ft
• Diameter of Beam 22 Ft
• Height of Beam 38″ from base to top of center post
• Weight 9 lbs
• Wind Load Area < 5 sq ft
• Power Handles full legal limit
