ARRL TLT4

Transmission Line Transformers 4th Ed.

-- by Jerry Sevick, W2FMI.

This fourth edition contains all the valuable information from earlier editions: the classic techniques of Guanella and Ruthroff as well as hundreds of real transformers constructed and measured to establish the practical levels of bandwidth and loss performance that can be obtained with transmission transformer techniques. This new edition expands the coverage of what is already the most comprehensive book on this subject.

Three new chapters cover:

• Transmission Line Transformer Efficiency
• Notes on Power Combiners and Mixer Transformers
• Equal-Delay Transformers
