Open Box Yaesu SP-8 External Speaker w/Filter SN141019
- Manual Frequency tailoring specifically intended for amateur and general communications modes.
- Wideband tailoring for: broadcast listening, music and FM reception.
- Independently-adjustable low-cut and high-cut filters offer twelve possible audio response configurations selectable from the front panel, enabling the operator select optimum response under all conditions and modes.
- Two separate inputs, selectable by a front panel switch.
- Two output jacks (1/4-inch and 3.5mm) for headphones are provided on the front panel.
- Adjustable front feet.
- Package includes: SP-8 Speaker, Patch cable (T9101275A), and instruction page
SPECIFICATIONS | SP-8 |
Frequency Range | 100 - 1200 Hz |
Filter Circuit Selections (approx): | |
LOW 1 | below 300Hz (-6dB/octave) |
LOW 2 | below 600Hz (-6dB/octave) |
HIGH 1 | above 2.4kHz (-6dB/octave) |
HIGH 2 | above 1kHz (-6dB/octave) |
HIGH 3 | above 700Hz (-6dB/octave) |
SSB | above 2.4kHz (low pass filter) |
CW | 600 - 700Hz (peak filter) |
