MFJ-1026 Deluxe Noise Canceling Signal Enhancer 1.5-30MHz

Name: MFJ-1026 Deluxe Noise Canceling Signal Enhancer 1.5-30MHz
Brand: MFJ
SKU: ZMF-1026
Price: 249.95 USD
Availability: InStock

MFJ Deluxe, Noise Cancel / Enhancer / Antenna MFJ-1026

SKU: ZMF-1026

Availability:

In stock

We'll Let You Know When It's Back On The Shelf

Thank you for your interest in this item.

Please note: Once you receive word that this item is available, it's up to you to act! An email notification guarantees neither inventory nor price. But don't worry: should you miss out on the first shipment, you can always request another notification.

$249.95

Quantity

Description

MFJ Deluxe, Noise Cancel / Enhancer / Antenna MFJ-1026

MFJ Noise Canceling Signal Enhancers

MFJ Noise Canceling Signal Enhancers are designed to reduce noise or interference, or improve desired signals, before the noise affects sensitive receiver circuits. Unlike conventional noise blankers, these units can be effective on all types of noise (QRN), as well as on interference (QRM) from unwanted signals. From the Broadcast Band to low VHF, these Noise Canceling Signal Enhancers work on all signal modes and can transform difficult receiving situations so you can finally hear, work, and log that rare DX!

MFJ Noise Canceling Signal Enhancers allow the user to adjust both phase and amplitude while combining antenna inputs. One of two antenna inputs may be connected to the transmit antenna, and the other to an external receive antenna or the internal whip antenna on the model MFJ-1026. Or both inputs may be used with identical receive antennas to create various directional patterns for optimum results. The signal output to the receiver or transceiver is the vector addition or subtraction of signals from two separate antennas, balanced and phased. This allows unwanted noise to be removed or desired signals to be enhanced.

Some other phasing systems provide either a limited phase adjustment range or change the signal's level as phase is adjusted. These MFJ units feature exceptional phase amplitude flatness that make it easy to adjust. Null out interfering signals or peak desired signals with the adjustment of a few controls and pull in that station you want to hear!

MFJ Noise Canceling Signal Enhancers are optimized over the range of 1.8 to 30 MHz and contain the interface circuitry necessary for operation with most modern HF transceivers. Although these signal enhancers contain internal RF sensing for T/R (transmit-receive) switching, we strongly recommend the use of the external T/R control connector on the rear panel for keying. These units run on 12 Vdc or 110 Vac with an optional adapter, sold separately.

You can null out noise or strong interference with MFJ Noise Canceling Signal Enhancers from GigaParts

Features

Wipe out Noise and Interference!

Wipe out noise and interference before it gets into your receiver with a 60 dB null!

Eliminate all types of noise -- severe power line noise from arcing transformers and insulators, fluorescent lamps, light dimmers, touch controlled lamps, computers, TV birdies, lightning crashes from distant thunderstorms, electric drills, motors, industrial processes.

Its more effective than a noise blanker because interference much stronger than your desired signal can be completely removed without affecting your signal.

It works on all modes -- SSB, AM, CW, FM, frequences from BCB to lower VHF.

Null out strong QRM on top of weak rare DX and then work him! You can null out a strong local ham or AM broadcast station to prevent receiver from overloading.

Use MFJ-1026 as an adjustable phasing network. You can combine two antennas to give you various directional patterns.

Null out a strong interfering signal or peak a weak signal at a push of a button.

Easy-to-use! Plugs between transmitting antenna and transceiver. To null, adjust amplitude and phase controls for minimum S-meter reading or lowest noise. To peak, push reverse button.

Use built-in active antenna or an external one. MFJ's exclusive Constant Amplitude Phase ControlTM makes nulling easy.

RF-sense T/R switch automatically bypasses your transceiver when you transmit. Adjustable delay time.

12 VDC or 110 VAC with MFJ-1312D. Measures 6 1/2WX 1 1/2H X 6 1/4D inches.

Specifications

Brand:	MFJ
Manufacturer's Part Number:	MFJ-1026
GigaParts Number:	ZMF-1026
Part Type:	Antenna Phasing and Noise Cancelling
Product Line:	MFJ Noise Canceling Signal Enhancers
Unit Type:	Noise canceller
Frequency Range:	1.5-30 MHz
AM Broadcast Band Coverage:	No
Total Phase Rotation:	Approx. 290 degrees
Precision Resettable Controls:	No
Phase Reversal Switch:	Yes
Receive Antenna Feedline Power Output:	No
PTT Keying Input:	Yes
PTT Keying Output:	No
Keying Connector Type:	RCA phono jack
Active Receive Verticals Included:	No
Unit Width:	6.500 in.
Unit Height:	1.500 in.
Unit Depth:	6.250 in.
Weight:	1.800 lbs.
UPC:	650619002072
Quantity:	1 Piece

Includes

MFJ Warranty Information
