Palstar DL2.5HP 2500W Dummy Load
The brand new Palstar DL2.5HP was the ham with the need for a dummy load that allows for more time to tune your amp at high power. Other dummy loads don't have the real world power load capability needed by Ham operators who run high-power amplifiers.
This Next-Generation Palstar DL2.5HP Dummy Load created for amateur radio and which is rated at 1 to 60 MHz can handle up to 2500 watts for up to 1 minute, and up to 600 watts for 100% duty cycle. The DL2.5HP has thermostatically-controlled dual fan cooling, so the fans only run when needed.
Power rating:Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â
• 2500 Watts for 1 min
• 600 Watts 100% duty
• 100°C temp max power
Frequency Range:Â Â Â Â Â Â Â Â Â Â Â
•1 to 60 MHz
Cooling:Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â
• Dual 240 cfm thermostatically controlled fans
•Fan turns on @ 45°C
Impedance:Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â
• 50 Ohms +/-5%
SWR:Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â
• Better than -20 dB R/L @ 1 - 60Mhz
Connector:Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â
• SO-329 Coax Input Connector
Metering:Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â
• Internal wattmeter and analog metering
Meter power range:Â Â Â Â Â Â
• 0-500 Watts/
• 0-5000 Watts
Power cable:Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â
• 3pin Amphenol DC Included (USA Only)
Chassis:Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â
• .090 ga. aluminium iridite coated
Top cover:Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â
• .090 ga. aluminium powder coated
Front cover:Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â
• .090 ga. aluminium powder coated
Dimensions:Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â
• 12" wide x 7" high x 13.5" deep
Shipping weight:Â Â Â Â Â Â Â Â Â Â Â Â Â
• 20 lbs (9.07 Kg)
