Digirig USBISO

• Eliminate audio noise caused by ground loops by isolating your PC from transceiver
• Remove hum noise in USB audio devices
• Protect your PC by isolating USB test equipment such as JTAG debuggers, USB oscilloscopes and programmers
• Signal isolation up to 2.5KV, power isolation up to 1.6KV
• Up to 1W load capacity, not recommended for charging drawing over 180mA
• Uses ADUM3160 for signal and B0505S for power isolation

Compatible with USB 1.0, USB 1.1, USB 2.0 Full/Low Speed only.

**USB 2.0 High Speed Devices are NOT supported**

• Weight:  0.1 lbs
• Dimensions:  5"×3"×0.75"
