Camera Width |
124.9 mm (4.92 in) |
Camera Height |
72.9 mm (2.87 in) |
Camera Depth |
39.1 mm (1.54 in) |
Camera Minimum Depth |
33 mm (1.3 in) |
Camera Body Weight |
Approx. 445g (0.98 lbs) including battery and memory card, Approx. 396g excluding battery and SD memory card |
Approximate External Lens Dimensions |
61.8mm × 23mm |
Lens Diameter |
61.8 mm |
Lens Length |
23 mm (0.91 in) |
Lens Weight |
90g (0.2 lbs) |
FPS Eligible |
Yes |
Family Type |
Hardware |
Warranty Duration |
365 days |
Filter Size |
39mm |
Focal Length |
23mm |
Number of Effective Pixels |
40.2 million pixels |
Image Sensor |
23.5mm x 15.6mm (APS-C) X-Trans CMOS 5 HR with primary color filter |
Sensor Cleaning System |
Ultra Sonic Vibration |
Storage Media |
SD Card (-2GB) / SDHC Card (-32GB) / SDXC Card (-2TB) / UHS-I / UHS-II / Video Speed Class V90 *Please visit https://fujifilm-x.com/support/compatibility/cameras/ to check memory card compatibility. |
Still Image File Format - DCF |
Compliant with Design rule for Camera File system (DCF2.0) |
Still Image File Format - JPEG |
Exif Ver.2.32 Exif 2.32 is a digital camera file format that contains a variety of shooting information for optimal printing |
Still Image File Format - TIFF |
8bit / 16bit RGB (In-camera Raw Conversion Only) |
Number of Recorded Pixels - [L] |
[4:3] 6864 x 5152 [3:2] 7728 x 5152 [16:9] 7728 x 4344 [5:4] 6432 x 5152 [1:1] 5152 x 5152 |
Number of Recorded Pixels - [M] |
[4:3] 4864 x 3648 [3:2] 5472 x 3648 [16:9] 5472 x 3080 [5:4] 4560 x 3648 [1:1] 3648 x 3648 |
Number of Recorded Pixels - [S] |
[4:3] 3456 2592 [3:2] 3888 x 2592 [16:9] 3888 x 2184 [5:4] 3264 x 2592 [1:1] 2592 x 2592 |
Number of Recorded Pixels - Vertical Panorama [L] |
2160 x 9600 |
Digital Tele-Converter |
2.0x, 1.4x, OFF |
Lens Mount |
FUJIFILM X Mount |
Sensitivity Standard Output |
STILL: AUTO1/ AUTO2/ AUTO3/ ISO125~12800 (1/3 step) MOVIE: AUTO/ ISO125~12800 (1/3 step) |
Sensitivity Extended Output |
[STILL:] ISO64/ ISO80/ ISO100/ ISO25600/ ISO51200 [MOVIE:] ISO25600 |
Exposure Control |
TTL 256-zone metering/ Multi/ Spot/Average/ Center Weighted |
Exposure Mode |
P (Program AE)/ A (Aperture Priority AE)/ S (Shutter Speed Priority AE)/ M (Manual Exposure) |
Exposure Compensation |
[STILL:] -5.0EV~+5.0EV (1/3EV step)/ [MOVIE:] -2.0EV~+2.0EV (1/3EV step) |
Image Stabilizer Mechanism |
Image sensor shift mechanism with 5-axis compensation |
Image Stabilizer Compensation Effect |
Center 7.0 stops and Periphery 6.0 stops (based on CIPA standard). Pitch/ Yaw/ Roll compensation, with XF35mmF1.4 R lens attached. |
Image Stabilizer Digital Image Stabilization |
Yes, movie mode only |
Image Stabilizer IS MODE BOOST |
Yes, movie mode only |
Shutter Type |
Focal Plane Shutter |
Synchronized Shutter Speed for Flash |
Mechanical Shutter: 1/180sec. or slower |
Continuous Shooting |
Electronic Shutter Approx. 20fps (1.29x Crop) (JPEG: 168 frames, Compressed RAW: 66, Lossless Compressed RAW 32, Uncompressed RAW: 17 frames, Compressed RAW + JPEG: 21 frames, Lossless Compressed RAW + JPEG: 20 frames, Uncompressed RAW + JPEG: 17 frames) Electronic Shutter Approx. 13fps (1.29x Crop) (JPEG: 1000+ frames ,Compressed RAW: 94, Lossless Compressed RAW: 25, Uncompressed RAW: 21 frames, Compressed RAW + JPEG: 48, Lossless compressed RAW + JPEG: 31, Uncompressed RAW + JPEG: 19) Electronic Shutter Approx. 10fps (1.29x Crop) (JPEG: 1000+ frames ,Compressed RAW: 536, Lossless Compressed RAW 21, Uncompressed RAW: 18 frames, Compressed RAW + JPEG: 24 frames, Lossless compressed RAW + JPEG: 24 frames, Uncompressed RAW + JPEG: 19 frames) Electronic Shutter Approx. 13fps (JPEG: 163 frames, Compressed RAW: 46, Lossless Compressed RAW 43, Uncompressed RAW: 23 frames, Compressed RAW + JPEG: 61 frames, Lossless compressed RAW + JPEG: 37 frames, Uncompressed RAW + JPEG: 21 frames) Electronic Shutter Approx. 8.9fps (JPEG: 1000+ frames, Compressed RAW: 68, Lossless Compressed RAW 28, Uncompressed RAW: 21 frames, Compressed RAW + JPEG:36 frames, Lossless compressed RAW + JPEG: 23 frames, Uncompressed RAW + JPEG: 21 frames) Mechanical Shutter Approx. 8fps (JPEG: 1000+ frames, Compressed RAW: 79, Lossless Compressed RAW 22, Uncompressed RAW: 20 frames, Compressed RAW + JPEG: 30 frames, Lossless compressed RAW + JPEG: 21 frames, Uncompressed RAW + JPEG: 20 frames) Mechanical Shutter Approx. 5.0fps (JPEG: 1000+ frames, Compressed RAW: 1000+ frames, Lossless Compressed RAW 56 frames, Uncompressed RAW: 24 frames, Compressed RAW + JPEG: 81 frames, Lossless compressed RAW + JPEG: 27 frames, Uncompressed RAW + JPEG: 21 frames) Mechanical Shutter Approx. 4.0fps (JPEG: 1000+ frames, Compressed RAW: 1000+ frames, Lossless Compressed RAW 1000+ frames, Uncompressed RAW: 29 frames, Compressed RAW + JPEG: 1000+ frames, Lossless compressed RAW + JPEG: 34 frames, Uncompressed RAW + JPEG: 26 frames) Mechanical Shutter Approx. 3.0fps (JPEG: 1000+ frames, Compressed RAW: 1000+ frames, Lossless Compressed RAW 1000+ frames, Uncompressed RAW: 60 frames, Compressed RAW + JPEG: 1000+ frames, Lossless compressed RAW + JPEG: 1000+ frames, Uncompressed RAW + JPEG: 34 frames) Recordable frames depends on recording media Speed of continuous shooting depends on shooting environment and shooting frames |
AE Bracketing |
AE Bracketing (Frames: 2, 3, 5, 7, 9 Step: by 1/3EV step, up to ±3EV steps) Film Simulation bracketing (Any 3 types of film simulation selectable) Dynamic Range Bracketing (100%, 200%, 400%) ISO sensitivity Bracketing (±1/3EV, ±2/3EV, ±1EV) White Balance Bracketing (±1, ±2, ±3) Focus Bracketing (AUTO, MANUAL) Multiple Exposure Yes (Max. 9 frames)- Additive, Average, Bright, Dark HDR Mode (AUTO, 200%, 400%, 800%, 800%+) Advanced filter Toy camera, Miniature, Pop color, High-key, Low-key, Dynamic tone, Soft focus, Partial color (Red / Orange / Yellow / Green / Blue / Purple) |
Focus Mode |
Single AF/ Continuous AF/ MF |
Focus Type |
Intelligent Hybrid AF (TTL contrast AF / TTL phase detection AF) |
Focus Low-light Performance |
Contrast: -4.0EV Phase Detection: -7.0EV *XF50mmF1.0 attached |
AF Frame Selection |
Single point AF: 13×9/ 25×17 (Changeable size of AF frame) Zone AF: 3×3/ 5×5/ 7×7 from 117 areas on 13×9 grid Wide/Tracking AF AF-S: Wide/ AF-C: Tracking All |
White Balance |
Auto (WHITE PRIORITY, AUTO, AMBIENCE PRIORITY)/ Custom1 - 3/ Color temperature selection (2500K–10000K)/ Preset Daylight, Shade, Fluorescent Light-1, Fluorescent Light-2, Fluorescent Light-3, Incandescent Light, Underwater |
Self-timer |
10sec./2sec. |
Interval Timer Shooting |
Yes (Setting : Interval, Number of shots, Starting time, Interval timer shooting exposure smoothing) |
Flash |
EF-X8 Guide Number approx. 11 (ISO200•m) / approx. 8 (ISO100•m) |
Flash Sync Mode |
EF-X8: 1st Curtain/ 2nd Curtain Shoe Mount Flash: 1st Curtain/ 2nd Curtain AUTO FP (HSS) Synchronized terminal: N/A |
Flash Mode |
TTL (TTL AUTO / STANDARD / SLOW SYNC. ) / MANUAL / MULTI * When EF-X500 is set/ OFF Synchronized terminal MANUAL |
Hot Shoe |
Yes (Dedicated TTL Flash compatible) |
Viewfinder EVF |
0.39 inch approx. 2.36 million dots OLED Color Viewfinder Coverage of viewing area vs. capturing area: approx. 100% Eyepoint: approx. 17.5mm (from the Rear End of the camera's Eyepiece) Diopter adjustment: -4~+2m-1 Magnification: 0.62× with 50mm lens (35mm equivalent) at infinity and Diopter set to -1.0m-1 Diagonal angle of view: approx. 31° (Horizontal angle of view: approx. 26° ) Built-in eye sensor |
LCD Monitor |
3.0 inch Tilt-Type (Three Direction) Touch Screen Color LCD Monitor Aspect Ratio 3:2 Resolution: Approx. 1.04 million dots |
Touch Screen Shooting Mode |
Shooting, AF, Focus Area, OFF, Double Tap Setting (ON/OFF), Touch Function Setting (ON/OFF), EVF Touch Screen Area Setting |
Touch Screen Playback Mode |
Swipe, Pinch-in / Pinch-out, Double-tap, Drag |
File format (Movie) |
MOV: HEVC/ H.265, Linear PCM / Stereo sound (24bit / 48KHz sampling) |MPEG-4, AVC/ H.264, Linear PCM / Stereo sound (24bit / 48KHz sampling) MP4: MPEG-4, AVC/ H.264, AAC |
Movie Compression |
All Intra/Long-GOP |
File Size / Frame Rate / Recording Time |
6.2K [16:9] - 6240×3150 29.97p/ 25p/ 24p/ 23.98p 200Mbps/ 100Mbps/ 50Mbps/ 25Mbps/ 8Mbps DCI 4K [17:9] - 4096×2160 59.94p/ 50p/ 29.97p/ 25p/ 24p/ 23.98p 200Mbps/ 100Mbps/ 50Mbps/ 25Mbps/ 8Mbps 4K [16:9] - 3840×2160 59.94p/ 50p/ 29.97p/ 25p/ 24p/ 23.98p 200Mbps/ 100Mbps/ 50Mbps/ 25Mbps/ 8Mbps Full HD [17:9] -2048×1080 59.94p/ 50p/ 29.97p/ 25p/ 24p/ 23.98p 200Mbps/ 100Mbps/ 50Mbps/ 25Mbps/ 8Mbps Full HD [16:9] - 1920×1080 59.94p/ 50p/ 29.97p/ 25p/ 24p/ 23.98p 200Mbps/ 100Mbps/ 50Mbps/ 25Mbps/ 8Mbps Full HD High speed rec. [17:9] - 2048x1080 240p/200p/ 120p/ 100p 200Mbps(recording) For recording movies, use a SD memory card with UHS Speed Class 3 or higher. For recording movies in 360Mbps, use a SD memory card with Video Speed Class 60 or higher. Selectable bitrate will be changed depends on the setting. Recording length can shorten depending on the temperature and/or shooting conditions |
Film Simulation Mode |
20 modes (PROVIA/Standard, Velvia/Vivid, ASTIA/Soft, Classic Chrome, REALA ACE, PRO Neg.Hi, PRO Neg.Std, Classic Neg., Nostalgic Neg., ETERNA Cinema, ETERNA BLEACH BYPASS, ACROS, ACROS + Ye Filter, ACROS + R Filter ACROS + G Filter, Black & White, Black & White + Ye Filter, Black & White + R Filter, Black & White + G Filter, Sepia) |
Clarity setting |
±5 steps |
Monochromatic Color |
Yes |
HDR Mode |
AUTO, 200%, 400%, 800%, 800%+ |
Grain Effect |
Roughness STRONG, WEAK, OFF, Size LARGE, SMALL |
Color Chrome Effect |
STRONG, WEAK, OFF |
Color chrome Blue |
STRONG, WEAK, OFF |
Smooth Skin Effect |
STRONG, WEAK, OFF |
Dynamic Range Setting |
AUTO, 100%, 200%, 400% ISO restriction (DR100%: No limit, DR200%: ISO320 or more, DR400%: ISO640 or more) |
Dynamic Range Setting (Movie) |
100%, 200%, 400% ISO restriction (DR100%: No limit, DR200%: ISO320 or more, DR400%: ISO640 or more) |
Advanced Filter |
Toy camera Miniature Pop color High-key Low-key Dynamic tone Soft focus Partial color (Red / Orange / Yellow / Green / Blue / Purple) |
Wireless Transmitter Standard |
IEEE802.11a/b/g/n/ac (standard wireless protocol) |
Wireless Transmitter Encryption |
WEP/WPA/WPA2 mixed mode |
Wireless Transmitter Access Mode |
Infrastructure |
Bluetooth® Standard |
Bluetooth Ver. 4.2 (Bluetooth low energy) |
Bluetooth® Operating frequency |
2402–2480MHz |
Terminal - Digital Interface |
USB Type-C (USB3.2 Gen2x1) |
Terminal - HDMI Output |
HDMI connector (Type D) |
Terminal - Others |
∅3.5mm, stereo mini connector (Microphone), Hot shoe |
Power Supply |
NP-126S Li-ion battery (included) |
Battery Life for Still Images |
Economy Mode Approx. 400 frames, Normal Mode Approx. 310 frames *When XF35mmF1.4 R is set |
Actual Battery Life for Movie Capture |
6.2K Approx. 45min. (29.97p) 4K Approx. 45min. (59.94p) Full HD Approx. 45min. (59.94p) |
Continuance Battery Life for Movie Capture |
6.2K Approx. 70min. (29.97p) 4K Approx. 70min. (59.94p) Full HD Approx. 80min. (59.94p) |
Operating Temperature |
0°C–40°C/ 32°F–104°F |
Start Up Period |
Approx. 0.5sec. |
Camera Item Includes |
Li-ion battery NP-W126S Headphone Adapter Shoulder strap Clip attaching tool Body cap |
Lens Configuration |
8 elements in 6 groups (includes 2 aspherical elements) |
35mm Equivalent Focal Length |
35mm |
Optical Image Stabilization |
No |
Autofocus |
Yes |
Lens Design |
Prime |
Angle of View |
63.4° |
Maximum Aperture |
F2.8 |
Minimum Aperture |
F16 |
Number of Aperture Blades |
11 (rounded diaphragm opening) |
Aperture Step Size |
1/3EV (16stops) |
Minimum Focus Distance (cm) |
20 |
Minimum Focus Distance (in) |
7.87 |
Magnification |
0.15x |
Lens Item Includes |
Front lens cap FLCP-39 II, Rear lens cap RLCP-001, Lens hood LH-XF27, Lens hood cap LHCP-27, Lens wrapping cloth |
Image Processing Engine |
X-Processor 5 |
