Pokit is the world's smallest Integrated Multimeter, Digital Storage Oscilloscope, and logger.
Please note that this is rated to 60v; it is not rated for Mainline 110V testing. Don't let the magic smoke out!
Measure Anything
Pokit measures, displays and logs a wide range of parameters including voltage, current, resistance and temperature. It also provides a continuity and diode checker. Pokit is intended for low voltage work up to audio frequencies.
Pokit is a full-featured Multimeter that accurately measures AC/DC voltage, AC/DC current, resistance and ambient temperature. It also includes a continuity and diode checker. Measurements are displayed directly on your smartphone in real-time. Simply touch to select a measurement mode.
True RMS measurement
Auto-ranging
Voltage: 10mV to 60V DC, 42V AC (RMS), +-1%
Voltage with optional HV probes: to 240V DC
Current: 1mA to 2Amax, +-1%
Resistance: 1 to 1M Ohm, +-5%
Ambient temperature: 1 to 60° C,+-1° C
Continuity and Diode polarity checker
Pokit DSO (Digital Storage Oscilloscope) captures detailed voltage and current waveforms for display on your smartphone. It also allows you to operate on the frequency domain using FFT, and use it as a spectrum analyzer. Simply pinch and drag to set the acquisition voltage scale and time base, and touch to select a trigger mode.
Captured waveforms are displayed in stunning detail. Pinch and drag to zoom and pan. Longpress on the graph to set cursors and trace your signals.
1MSamples/sec, 14-bit sampling
Voltage: 10mV to 60V DC, 42V AC (RMS), +-1%
Current: 1mA to 2Amax, +-1%
10ms to 10s acquisition window
Auto trigger or adjustable rising/falling trigger level
Pokit functions as a stand-alone data logger that logs temperature, voltage or current waveforms for periods up to 6 months without connection to a phone. Waveforms can be uploaded to your phone for display.
14-bit sampling
Voltage: 10mV to 60V DC, 42V AC (RMS), +-1%
Current: 1mA to 2Amax, +-1%
1 to 8000 points memory
Up to 6 months logging
Measure Anywhere
Pokit fits on your keychain! With leads that retract at the press of a button, Pokit is convenient and small enough to take anywhere!
Measure with Ease
Pokit connects wirelessly to your smartphone and app. It's amazingly easy to use. Simply touch to change modes and settings, and pinch and drag to pan and zoom waveforms. After using Pokit you'll wonder why all tools weren't designed this way!
THE POKIT APP
Transform your mobile phone into an awesome tool.
The Pokit App is available for Android and iPhone.
High-resolution data display
Touch to select modes and settings
Pinch and drag to zoom and pan waveforms
Monitor connectivity and battery status
State-of-the-art electronics in an innovative design
