| Property | Test Method | Mil Spec Min. Performance | Test Results |
|---|---|---|---|
| Operating Temperature Range | -65° C to 260° C | -65° C to 260° C | |
| Continuous Temperature Range | -60° C to 200° C | -60° C to 200° C | |
| Cold Brittle Point | -65° C | -65° C | |
| Hardness Shore A | ASTM D2148 | 50 | 50 |
| Tensile Strength, Min. | ASTM D119 | 700 PSI | 950 PSI, +/- 25 PSI |
| Elongation, Min. | ASTM D119 | 300% | 800%, +/- 50% |
| Tear Strength, Min. | ASTM D624, Die B | 85 ppi | 85 ppi |
| Bond Strength, Min. | MIL-I-46852 | 2 lbs | 12 lbs |
| Cold Brittle Point, Max. | ASTM D746 | -65° C | -65° C |
| Water Absorption, Max. | MIL-I-46852 | 3% By Weight | 3% By Weight |
| Dielectric Strength, Min. | MIL-I-46852 | 400 v/mil (8,000 Volts/20mil) | 400 v/mil (8,000 Volts/20mil) |
