ASTRON RS-50M-AP POWER SUPPLY

FOLD BACK CURRENT LIMITING Protects Power Supply from excessive current and continuous shorted output

CROWBAR OVER VOLTAGE PROTECTION ON ALL MODELS

MAINTAIN REGULATION AND LOW RIPPLE at low line input Voltage

THREE CONDUCTOR POWER CORD

HEAVY DUTY HEAT SINK

INPUT VOLTAGE: 105-125VAC

OUTPUT VOLTAGE: 13.8VDC ±0.05 volts?

INTERNALLY ADJUSTABLE VOLTAGE (11-15VDC)

RIPPLE: LESS THAN 5MV PEAK TO PEAK (full load and low line)

LOAD REGULATION: 0.08% from 0 to Full Continuous Load??

EFFICIENCY: 77%

OPERATING TEMP: -10 to 55°C

ANDERSON POWER POLES INSTALLED IN -AP MODELS
