BITX40 - 40M SSB Transceiver Module Kit

$69.99
BITX40 - 40M SSB Transceiver Module Kit SKU: ZHS-BITX40

$69.99

Ready to Ship!
Check Store Stock

Huntsville Store:

Las Vegas:

BITX40 - 40M SSB Transceiver Module Kit by HF Signals

When was the last time you used a radio you had built? The BITX40 board is a two board, 40 meter SSB transceiver module kit with digital control! Inside an evening, you can be on-air with this digital SSB transceiver, chatting with the local gang or chasing DX. Plug in the earphones, the included electret mic, tuning and volume controls and you are on air! Included are high-quality connectors, all the needed sockets and jacks, tuning and volume controls, mounting hardware, etc.

The Raduino The new BITX40's Raduino is an Arduino Nano powered, small, hackable board based on the rock steady Si5351 synthesizer with a clean 16x2 frequency display, free and open source code, 6 analog ports, three oscillators and six digital lines.

Receiver The listen to the very clean, crisp and quite receiver. The front-end has a triple tuned circuit that cuts out-of-band signals. The diode ring mixer front-end makes this a crisp receiver that doesn't overload easily. The all-analog signal path to your ear provides outstanding signal clarity that is to be heard to be believed.

Transmitter 7 watts of low distortion SSB provides you with enough juice to have thousands of contacts on 40 meters, daily rag chew and occasional DX chasing. Any common 2 amperes 12 linear volts supply will provide enough juice for this transceiver. Or you could simply run it from a battery!

Hackable

The BITX40 will inspire you to experiment. Modify it, mount it, tweak it, change it.

Raduino is a standard Arduino Nano that makes it easy to write code in simple C language to work on more modes, bands, utilities. RIT, dual VFOs, more bands, CW/RTTY are just some code away! who will be the first to the Raduino keyer?

The main board uses all analog large sized SMD components that are laid out in an easy to understand manner on a double-sided board with broad tracks. This can be your main module around which you can start experimenting. There are jump-points from where you can add more modules like the DDS, more bands, better audio amplifier, etc. Imagination is your limit. You can separately increase the power amplifier's supply voltage to 25 volts to be more than 20 watts of power: You will have to add a better heatsink. The mods are on the way!

The boards can be installed inside any box that you like. Make your own station rigs, man-packs, SOTA rigs, trail radio or mount it in a cigar box and leave it on your bedside table.

The Raduino The new BITX40's Raduino is an Arduino Nano powered, small, hackable board based on the rock steady Si5351 synthesizer with a clean 16x2 frequency display, free and open source code, 6 analog ports, three oscillators and six digital lines.

Receiver The listen to the very clean, crisp and quite receiver. The front-end has a triple tuned circuit that cuts out-of-band signals. The diode ring mixer front-end makes this a crisp receiver that doesn't overload easily. The all analog signal path to your ear provides outstanding signal clarity that is to be heard to be believed.

Transmitter 7 watts of low distortion SSB provides you with enough juice to have thousands of contacts on 40 meters, daily rag chew and occasional DX chasing. Any common 2 ampere 12 linear volts supply will provide enough juice for this transceiver. Or you could simply run it from a battery!

  • 4-1/2 inches by 5 inches tested SSB transceiver module, covering any 400 KHz segment of the 7 MHz band
  • The Raduino board with Si5351, Arduino Nano. Fully tested
  • High quality BNC connector for the antenna
  • Small electret microphone
  • Two earphone style audio jacks for the mic and the earphones/speaker
  • A set of DC power socket and plug
  • Volume control with on/off switch
  • 10k linear pot for tuning
  • 8 Brass stand-offs with mounting nuts and bolts
  • Connectors with wires for all connections on the board
