BridgeCom Systems BCR-220 (220 MHz) Repeater
Looking to get into the 1.25m (220 MHz) band? Struggling, with your current repeater, or lack thereof? Is your club or organization having issues with the system your currently using? Well, don’t give up hope because we have the solution for you.
The BridgeCom Systems BCR-220 FM Repeater is built for amateur ham radio. It operates in 222-225 MHz 1.25m range of the RF spectrum. The BCR Repeater is a feature-rich repeater/base station packed with loads of RF power and dual fans to run cool in the harshest environments. It is an excellent choice if you're considering a 220 repeater for your club or personal use. It is also an excellent choice for A.R.E.S./R.A.C.E.S. operation, and emergency management. Get on the 1.25m band today with a built in the USA BCR-220 repeater.
When you place your order please include Tx/Rx Frequency, PL Tone In/Out, Station ID, Desired Transmit Output Power within the Notes Field during checkout.
- 1.25m (222-225 MHz) - 30 Watts Continuous Duty
- Digital Ready for Amateur Dual Mode (Digital/Analog)
- Designed and assembled in the USA
- 2 - year warranty
- Windows® Based Programmer (Sold Separately)
- Built-In 11.2A Power Supply
- Battery Backup with Built-in Charging Circuit
- Dual Cooling Fans
- Front Panel Speaker
- 25-pin Accessory Connector
- Adjustable Squelch
- 12.5 kHz/25 kHz Channel Spacing
- Over-the-Air Programming and Maintenance via DTMF Tone Sequences
- Built-in station CWID - Morse rate programmable 10-25 wpm
- The MAX TX POWER when transmitting 30Watts is ~8 Amps
- Quiescent draw is around ~250mA
