Alinco DJ-MD5XT Dual-Band DMR Handheld Transceiver with GPS

Alinco's 2nd Generation Advanced Dual Band DMR VHF/UHF DJ-MD5XT HT Part 90 with GPS transceiver to its existing line-up of Digital Commercial/Business or Amateur Radio handhelds. The DJ-MD5XT has a compact and durable IP54 Rated polycarbonate body, designed to resist dust and splash. The DJ-MD5XT has features such as Color LCD Display, 5W Output Power, up to 4000 Memory Channels and Built-in GPS. Capable of operating in Digital and Analog with mixed mode in VFO or Memory mode.

The DJ-MD5XT utilizes DVSI's AMBE+2 vocoder for Crystal clear DMR digital audio for use in noisy environments like contraction sites, parks, security applications or your favorite repeaters coverage area with no noise or fading even in low lying areas. The DJ-MD5XT has powerful audio output power to insure loud crisp receive audio.



WARNING

ATTEMPTED USE WITH 3RD PARTY MICROPHONES WILL VOID THE WARRANTY

AND MAY RESULT IN PERMANENT DAMAGE TO THE RADIO.

  • LCD Display: Vibrant 1.77in Color LCD Display, enhances user experience with detailed and clear Radio Activity in both Bands as the same time.
  • Higher Channel: Available 4000 Memory Channel capacity and 200,000 contacts allows users to maximize their entire list of Favorite Talkgroups.
  • GPS Capability: GPS position reporting
  • 2-Slot TDMA DMR Tier I and Tier II
  • 1.77 inch TFT color LCD
  • GPS Built-in
  • APRS Support (Digital/Analog)
  • Automatic Repeater Roaming
  • Area SQL Function
  • AES 256bit Encryption (Digital mode)
  • VFO/MR Switch
  • Output power selectable (5W/2.5W/1W/0.2W)
  • 4000 channel memory, 250Zone, 250 Scan lists
  • SMS (Digital mode)
  • Communication recording (Digital mode)
  • Individual/Group/All call (Digital mode)
  • CTCSS/DCS/DTMF/2Tone/5Tone encode and decode (Analog mode)
  • Selectable battery-save
  • 1700mAh Li-ion battery
  • FCC Part 90 / IC RSS119 Certified
Frequency Coverage

VHF 136-174MHz / UHF 400-480MHz

Modulation

Two-Slot TDMA (Tier 1/ Tier II)

Channel Capacity

4000

Zone Capacity

250 Zones (250CH/ Zone)

Channel Spacing

Digital 12.5KHz Analog 12.5KHz/25KHz

Operating Voltage

DC 7.4V normal

Operating Temperature Range

-4°F~122°F (-20°C~ +55°C)

Frequency Stability

+/-2.5ppm

Antenna Impedance

50 ohms

Battery

1700mAH Li-ion (EBP-88)

Dimensions (w/Batt.)

2.32 x 4.65 x 1.57 in. (W x H x D)

Weight (w/Batt.)

Approx. 256 g /9.03 oz (w/Batt. & Antenna)

Certifications

FCC Part 90/ IC RSS119 Certified

TRANSMITTER
Output power

5W/ 2.5W/ 1W/ 0.2W

FM Hum and Noise

25KHz: 45dB 12.5KHz: 40dB

Spurious Emission

-36dBm@<1GHz, -30dBm@>1GHz

Adjacent Channel Power

60dB@12.5KHz, 70dB@25KHz

Modulation (Digital)

7K60FXD/7K60FXE

Modulation (Analog)

16K0F3E/11K0F3E

Digital Vocoder

AMBE+2 (DVSI)

RECEIVER
Analog Sensitivity

25kHz: 0.2uV 12kHz: 0.25uV

Digital Sensitivity

5% : 0.3μV 1% : 0.7μV

Intermodulation

60dB

Spurious Response Rejection

70dB

Audio Output

1W/ 16ohms

Audio Distortion

Less than 5% (typical)
