Genasun Waterproof MPPT Voltage Boosting Solar Controller for LiFEPO4 Batteries with Aptiv Connectors

SKU
ZGN-GVB8LI-14.2-WPGP
$159.95
Add to Wish List
Ready to Ship!

Genasun Waterproof MPPT Voltage Boosting Solar Controller for LiFEPO4 Batteries with Aptiv Connectors

The Genasun GV-8 LiFePO4 Waterproof solar controller is an excellent choice for anyone who needs a high-quality, efficient, and reliable solar charge controller for their LiFePO4 battery system in a harsh, wet or marine environment. Here are some reasons why:

  • Waterproof Design: The GV-8 LiFePO4 Waterproof controller is designed with a fully waterproof and dustproof casing, making it ideal for use in wet and harsh outdoor environments. It can handle exposure to rain, saltwater, and other moisture and humidity without any damage.

  • Designed for LiFePO4 Batteries: Like the non-waterproof version, the GV-8 LiFePO4 Waterproof controller is specifically designed to work with LiFePO4 batteries, which have different charging requirements than traditional lead-acid batteries. It uses advanced algorithms to optimize the charging process and ensure that your batteries are charged safely and efficiently.

  • High Efficiency: The GV-8 LiFePO4 Waterproof controller boasts an impressive 99% efficiency rating, which means that it converts nearly all of the power generated by your solar panels into usable energy for your batteries.

  • Advanced MPPT Technology: The GV-8 LiFePO4 Waterproof controller uses advanced Maximum Power Point Tracking (MPPT) technology to maximize the amount of energy your solar panels produce, ensuring that your batteries are charged as efficiently as possible.

  • Intelligent Battery Management: The GV-8 LiFePO4 Waterproof controller includes a number of built-in safety features to protect your batteries from overcharging and over-discharging, ensuring that they have a long and reliable lifespan.

  • Easy to Install and Use: The GV-8 LiFePO4 Waterproof controller is designed for easy installation and setup, with a simple and intuitive user interface that makes it easy to monitor and control your solar power system.

Overall, the Genasun GV-8 LiFePO4 Waterproof solar controller is a top-quality choice for anyone who needs a reliable and efficient solar charge controller that can handle the harsh and wet environment. Its waterproof design, specialized design for LiFePO4 batteries, high efficiency, advanced MPPT technology, intelligent battery management, and user-friendly interface make it an excellent investment for anyone who wants to power their life with solar energy in wet or marine environments.



  • Aptiv connectors for direct use with powerfilm panels!
Specifications GVB-8-Li-14.2V-WP
Battery Type: 12V (4S) LiFePO4
Max Recommended Panel Power:1 105 W
Rated Panel (Input) Current:1 8A
Max Recommended Panel Vmp: 13V
Max Input (Panel) Voltage: 60V
Recommended Max Panel Voc at STC: 50V
Input Voltage Range: 0V - 60V
Minimum Input (Panel) Voltage for Charging: 5V
Max Input Short Circuit Current:1,2 8A
Maximum Input Current:3 15A
Minimum Battery Voltage for Operation: 9.5V
Trickle Charge to Recover Dead (0V) Battery: Yes
Operating Temperature: -40°C – 85°C
Maximum Full Power Ambient:4 70°C
Charge Profile: CC/CV
CV Voltage: 14.2V
Battery Temperature Compensation: Disabled
Electrical Efficiency: 95%-97% typical
Standby Consumption: 7mA
MPPT Tracking Speed: 15Hz
Connection: Flying Leads, 16 AWG tinned wire, pre-stripped
Weight: 10.3oz (290g)
Dimensions: 5.5" x 3.2" x 2.2" (14cm x 8.1cm x 5.5cm)
Environmental Protection: IP68 (Waterproof)
Warranty: 5 years
Certifications: CE, FCC, and RoHS
1: Panel ratings have increased since we designed the GVB-8-WP. Although we don't believe in changing specifications without a corresponding engineering change, based on both our customers' experiences over the years as well as the headroom we designed into the GVB-8-WP, we feel comfortable recommending the GVB-8-WP for panels with Imp up to 9 A.
2: Panel Isc. Max input power and maximum input voltage requirements must also be respected.
3: Max current that the controller could draw from an unlimited source. This specification is not intended for determining PV input.
4: Max ambient temperature for full operating power
