Intel SSDPEDMW400G4X1

Model

Brand

Intel

Series

750 Series

Model

SSDPEDMW400G4R5

Device Type

Internal Solid State Drive (SSD)

Details

Form Factor

HHHL (CEM2.0)

Capacity

400GB

Memory Components

MLC

Interface

PCIe NVMe 3.0 x4

Performance

Max Sequential Read

Up to 2200 MBps

Max Sequential Write

Up to 900 MBps

4KB Random Read

Up to 430,000 IOPS

4KB Random Write

Up to 230,000 IOPS

Read Latency

20 µs

Write Latency

20 µs

MTBF

1,200,000 hours

Environmental

Power Consumption (Idle)

4W

Power Consumption (Active)

12W

Operating Temperature

0°C ~ +55°C

Max Shock Resistance

50 G Trapezoidal, 170 in/s

Max Vibration Resistance

Operating: 2.17 GRMS (5-700 Hz)
Non-Operating: 3.13 GRMS (5-800 Hz)

Dimensions & Weight

Height

18.74mm

Width

68.90mm

Depth

168.00mm

Weight

195.00g

Package Content

Package Content

With full bracket and half height bracket in the box
