Intellitron AR-600 Digital Antenna Rotator with Remote and Mounting Hardware

Intellitron AR-600 Programmable Digital Antenna Rotator

Intellitron: "Expertly Built, Economically Priced"

The Intellitron AR-600 Programmable Digital Antenna Rotator offers amateur radio enthusiasts a robust and intelligent solution for precise antenna positioning. Embodying Intellitron's commitment to "Expertly Built, Economically Priced" products, the AR-600 delivers advanced features and reliable performance, making sophisticated antenna control accessible to all hobbyists.

The AR-600 Drive Unit features a durable design for outdoor installation. It connects to your control unit using a 3-conductor cable (20AWG for up to 280 feet / 84m; thicker gauge for longer distances). Installation is straightforward, involving opening a cover, inserting the cable through a grommet, and connecting leads to terminals 1, 2, and 3, ensuring secure, short-circuit-free connections.

Mounting the drive unit is simple: attach it to a support mast (1 1/4" to 2" / 3-5cm diameter recommended) by loosening clamp nuts, resting the cast nose on the mast, and moderately tightening. For added stability, guy wires can be passed through the lower clamp's holes.

The indoor control unit is designed for ease of use and programming. After wiring the rotor cable to the connector plate, simply plug the control unit into a 120 VAC outlet (do not use 240 VAC).

Key Features & Programming:

• Digital Control: Programmable system for precise antenna positioning.
• Easy Synchronization: The system quickly synchronizes the control unit with the rotator by pressing the INITIAL key.
• 360° Calibration: Calibrate for a full 360° range with a simple key combination.
• Memory Positions: Store up to 12 favorite antenna positions (A-L) for quick recall, with the display value multiplied by 10 to get the correct heading.
• Automatic & Manual Operation: Rotate the antenna automatically to a stored position or use clockwise/counterclockwise keys for manual adjustments and fine-tuning.
• Movement Interruption: Stop rotator movement instantly by pressing a directional key.
• Resynchronization: Easily re-synchronize the rotator after power outages or misalignment by pressing the INITIAL key.
• Robust Construction: Durable drive unit for outdoor installation.
• Flexible Cabling: Supports up to 280 feet of 20AWG 3-conductor cable for drive unit connection, with options for longer distances using thicker gauge.
• Adjustable Mast Compatibility: Accommodates mast diameters between 1 1/4" to 2".

UPC Code: 810106911458
