CPU |
Intel® Socket 1151 for 7th/6th Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors |
|
Supports Intel® 14 nm CPU |
|
Supports Intel® Turbo Boost Technology 2.0 |
|
* The Intel® Turbo Boost Technology 2.0 support depends on the CPU types. |
|
* Refer to www.asus.com for CPU support list |
|
|
Chipset |
Intel® B250 |
|
|
Memory |
2 x DIMM, Max. 32GB, DDR4 2400/2133 MHz Non-ECC, Un-buffered Memory |
|
Supports Intel® Extreme Memory Profile (XMP) |
|
* Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists). |
|
* Due to Intel® chipset limitation, DDR4 2400MHz memory frequency is only supported by 7th Generation Intel® processors. Higher memory modules will run at the maximum transfer rate of DDR4 2400MHz. |
|
** Due to Intel® chipset limitation, DDR4 2133MHz and higher memory modules on 6th Generation Intel® processors will run at the maximum transfer rate of DDR4 2133MHz. |
|
|
Graphic |
Integrated Graphics Processor- Intel® HD Graphics support |
|
VGA output support : HDMI port |
|
- Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz |
|
Maximum shared memory of 1024 MB |
|
|
Expansion Slots |
1 x PCIe x16 (x16 mode) |
|
18 x PCIe x1 |
|
|
Storage |
4 x SATA 6Gb/s port(s), |
|
|
LAN |
Intel® I219V, 1 x Gigabit LAN Controller(s) |
|
|
Audio |
Realtek® ALC887 8-Channel High Definition Audio CODEC |
|
|
USB Ports |
Intel® B250 Chipset : |
|
6 x USB 3.1 Gen 1 port(s) (4 at back panel, , Type-A, 2 at mid-board) |
|
Intel® B250 Chipset : |
|
4 x USB 2.0/1.1 port(s) (2 at back panel, , 2 at mid-board) |
|
|
Special Features |
ASUS 5X Protection III : |
|
- ASUS SafeSlot Core: Fortified PCIe Slot prevents damage |
|
- ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges! |
|
- ASUS Overvoltage Protection: World-class circuit-protecting power design |
|
- ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability! |
|
- ASUS DIGI+ VRM: 6 Phase digital power design |
|
|
Back I/O Ports |
1 x PS/2 keyboard (purple) |
|
1 x PS/2 mouse (green) |
|
1 x HDMI |
|
1 x LAN (RJ45) port(s) |
|
4 x USB 3.1 Gen 1 (blue) Type-A |
|
2 x USB 2.0 |
|
3 x Audio jack(s) |
|
|
Internal I/O Ports |
1 x USB 3.1 Gen 1 connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin) |
|
1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s) |
|
1 x COM port(s) connector(s) |
|
4 x SATA 6Gb/s connector(s) |
|
1 x CPU Fan connector(s) (1 x 4 -pin) |
|
1 x Chassis Fan connector(s) (1 x 4 -pin) |
|
1 x S/PDIF out header(s) |
|
1 x 24-pin EATX Power connector(s) |
|
1 x 8-pin ATX 12V Power connector(s) |
|
1 x Front panel audio connector(s) (AAFP) |
|
1 x System panel(s) |
|
3 x 4-pin AUXPWR Header |
|
|
Accessories |
User's manual |
|
I/O Shield |
|
2 x SATA 6Gb/s cable(s) |
|
1 x Supporting DVD |
|
|
BIOS |
64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, WfM2.0, SM BIOS3.0, ACPI 6.0, ASUS EZ Flash 3, Last Modified log, F12 PrintScreen, F3 Shortcut functions and ASUS DRAM SPD (Serial Presence Detect) memory information |
|
|
Manageability |
WfM 2.0, DMI 3.0, WOL by PME, PXE |
|
|
Operating System |
Windows® 10 64-bit |
|
Windows® 7 64-bit *1 |
|
|
Form Factor |
ATX Form Factor |
ATX Form Factor |
12 inch x 9.1 inch ( 30.5 cm x 23.1 cm ) |
|
|
Note |
1.Windows® 7 64-bit is only supported when using 6th Generation Intel® Processors |
