| Receiving modes: |
AM, FM, FM-MOT (Motorola), LTR(EF Johnson), CTCSS, DCS, NAC on P25, EDACS wide/narrow(GE/Ericsson/HARRIS), P25-Phase I, X2-TDMA, P25-Phase II,DMR, MotoTRBO™ Tier II |
| Receiving system: |
Triple conversion PLL super heterodyne |
| WX frequencies: |
162.400, 162.425, 162.450, 162.475, 162.500,162.525, 162.550 MHz |
| Display: |
Full dot matrix bitmap LCD (132x65 dots) |
| Sensitivity: |
(FM 12 dB SINAD unless otherwise noted) |
| VHF Low: |
0.2 μV |
| VHF Aircraft (AM): |
0.4 μV |
| VHF High 137-174 MHz: |
0.3 μV |
| VHF High 216-300 MHz: |
0.4 μV |
| UHF Low 300-406MHz: |
0.8 μV |
| UHF/UHF-T 406-512 MHz: |
0.4 μV |
| UHF High 764-960 MHz: |
0.5 μV |
| 1240 - 1300 MHz: |
0.5 μV |
| Squelch sensitivity (band center) |
|
| Threshold: |
AM/FM 0.5 μV |
| Tight: |
(S+N)/N: AM 20 dB, FM 25 dB |
| Spurious rejection: |
VHF High at 154.1 MHz: 40 dB(Except Primary image) |
| Signal to noise ratio: |
35-40 dB typical(100 μV input signal) |
| Scanning rate without trunking: |
138-147.9MHz:70ch/second(in 100 kHz Intervals) |
| Search rate: |
162.25-167.25 MHz: 80 steps/sec. |
| Scan and Search delay time: |
2 seconds |
| Audio max. power RF input: |
100 μV at 154.1 MHz(DEV:3kHz at 1kHz) |
| 8 Ohms Resistor Load at speaker terminal(BTL): |
500 m Watts |
| Intermediate frequency: |
|
| 1st: |
380.8 MHz |
| 2nd: |
21.4 MHz |
| 3rd: |
455 kHz |
| Antenna impedance: |
50 Ohms |
| Temperature range (optimal): |
-10°C to 60°C |
| Speaker: |
Built-in 77 mm 8 Ohms dynamic speaker |
| Operating voltage: |
12-14.4 VDC, 13.8 VDC nominal(16 VDC maximum) |
| Dimensions (HWD): |
1.75 x 7.125 x 5.31 inch (45 x 180 x 135 mm) |
| Weight: |
33.5 oz. (9500g) Without antenna |
