Yaesu G-450A

Yaesu G-450A SKU: ZYS-G-450A


Free Shipping!

Reserve yours now!
(Ships In 7-14 Days)

Check Store Stock

Huntsville Store:

Las Vegas:

The Yaesu G-450A is the ideal antenna rotator for VHF and UHF antennas or small tri banders. The G-450A handles a wind load of 10 Sq. Ft. and a vertical load of 242 pounds. This rotator offers 450 degrees of azimuth rotation plus 180 degrees of rotation.


Power Supply Voltage: 117 VAC, 50-60 Hz
Power Supply Current Consumption: 0.5 Amps
Rotor Voltage: 24 VAC
Cable Conductors Required: 6
360° Rotation Time (Non Loaded): 63 seconds at 50 Hz
0 51 seconds at 60 Hz
Rotation Range: 450°
Rotation Torque: 43 ft-lbs
Braking Torque: 217 ft-lbs
Maximum Vertical Load: 242 Lbs. (100 kg) Continuous
  660 Lbs. (300 kg) Instantaneous
Mast Outside Diameter: 1.25 - 2.5 inches (32 to 63mm)
Braking Type: Mechanical stopper
Antenna K Coefficient: 100 or less
Wind Loading Area: (Pole Type) 0.5 m2 or less
(Tower Type) 1.0 m2 or less
Maximum Continuous Duty: 3 minutes
Operating Temperature Range: 0°C to +40°C (Controller)
0 -20°C to +40°C (Rotator)
Rotator Dimension: 7.32 x 10.35 inches
Rotator Weight: 7.71 lbs
Controller Dimension (WHD): 7.48 x 4.92 x 5.90 inches
Controller Weight: 5.95 lbs
