ABR Industries 218XATC-PL-BM-6.0
6.0ft RG8x Coax Jumper with PL259 to BNC Male Plug
Weather-Proof Heat Shrink Tubing (HST) Each End.
Stranded Center Conductor
95% TC Braid + bonded 100% Foil Shield
Very Flexible, Light Weight, and Smaller than RG8 sizes.
Perfect for Mobile, Dipoles, & Portable, Condos, and Apartments.
Non-Contaminating-UV Resistant-Direct Burial-Black Jacket.
No need for conduit.
Gas Injected Foam Polyethylene Dielectric VP: 82%
our GIFP dielectric is a major feature advantage over standard RG8x; those products use a chemical foam dielectric; higher losses, will-not stand-up to heat, ergo causing the center conductor to migrate into the braid, and shorting-out.
Voltage DC: 1500Volts RMS: 5000
Maximum permissible D.C. voltage level is conservatively 3 times the A.C. level.
PP kW: 5.6
Overall Diameter: .242″
All cable are fully tested. Hi-Pot® and continuity.
Nominal Attenuation-per 100ft/Power Rating(kW)/Efficiently%
0.9dB @ 10MHz/2.16kW/80% E.
1.4dB @ 30MHz/1.24kW/69% E.
2.1dB @ 50MHz/.96kW/62% E.
3.6dB @ 150MHz/0.55kW/43.5% E.
6.3dB @ 450MHz/0.31kW/23.2% E.
