Icom IC-2730A 50W VHF/UHF Dual-Band Mobile Transceiver with Bluetooth

SKU
ZIC-2730A
Rating:
80 % of 100
$309.95
Add to Wish List
Ready to Ship!

Icom IC-2730A Dual-band Mobile Radio VHF/UHF

The IC-2730A provides VHF/VHF, UHF/UHF simultaneous receive capability as well as VHF/UHF receive. Main dials, volume, squelch knobs and primal buttons are symmetrically laid out for each band.  It's display size is 1.5 times larger than its predecessor IC-2720H.  The frequency and channel panel are larger, also has a white backlight that provides higher contrast.  The Icom IC-2730A provides provides a durable PA mofule and is able todliver 50 watts of higher power operation on both VHF and UHF banks.  This radio has CTCSS and DTCS tone that are bulitl-in for quite stand-by and repeater access.  Split tone function allows you to set CTCSS and DTCS tones separately.

You will be able to listen to aviation, marine, weather channels as well as other utility communications.

Purchase your Icom IC-2730A Dual-band Mobile Radio VHF/UHF from GigaParts today.

UPC: 731797022233

VHF/VHF, UHF/UHF simultaneous receive

The IC-2730A provides VHF/VHF, UHF/UHF simultaneous receive capability as well as VHF/UHF receive. Main dials, volume, squelch knobs and primal buttons are symmetrically laid out for each band.

Optional VS-3 Bluetooth® headset

The optional VS-3 Bluetooth® headset can wirelessly control the IC-2730A with three programmable and a PTT button. It also provides VOX operation for hands-free communication. (Optional UT-133 Bluetooth® unit must be installed in the IC-2730A.)

Easy-to-See large white backlight LCD

The display size of the IC-2730A is 1.5 times larger than its predecessor, the IC-2720H. Frequency display and channel names are larger, and the white backlight provides higher contrast.

Easy controller mounting with the optional MBF-1

The combination of the optional MBF-1 suction cup mounting base and MBA-5 controller bracket provides easy tilt and swivel adjustments. The large suction cup can be mounted on flat surfaces and can be removed easily.

50 Watts of output on VHF and UHF

The IC-2730A employs a durable PA module and delivers 50 watts of high power operation on both VHF and UHF bands.

Built-in 50 CTCSS and 104 DTCS tones with split tone function

The CTCSS and DTCS tones are built-in for quiet stand-by and repeater access. The split tone function allows you to set CTCSS/ DTCS tones separately for repeater uplink and downlink on a per channel basis.

Controller attachment to the main Unit with optional MBA-4

With the optional MBA-4 combination bracket, the controller can be attached to the main unit. The microphone jacks are mounted on both the controller and main unit.

Wideband receiver

The IC-2730A covers 118–174 and 375– 550MHz. You will be able to listen to aviation, marine, weather channels and other utility communications.



Mode

F2D, F3E

Type of emission

F2D, F3E (FM)

No. of memory channels 1052 channels (including 50 scan edges and 2 Call)
Frequency stability ±2.5ppm
Operating temp. range

–10°C to +60°C; 14°F to +140°F

Frequency stability

±3ppm (–10°C to +60°)

Power supply requirement:

13.8V DC ±15%
Current drain (at 7.4V DC):

Transmit

Receive


13A

1.8A/1.2A (Max. audio/Stand-by)

Antenna impedance 50Ω (SO-239)
Dimensions (W×H×D)
Main Unit
Controller

150×40×151 mm; 5.91×1.57×5.94 in
150×50×27.2 mm; 5.91×1.97×1.07 in
Weight (approx.)
Main Unit
Controller

1.2 kg; 2.65 lb
140 g; 4.94 oz
Transmitter
Output power (at 13.8V DC)

TPE version

50W, 15W, 5W

25W, 15W, 5W

Max. frequency deviation ±5.0kHz/±2.5kHz (W/N)
Spurious emissions Less than –60dBc
Microphone impedance 60Ω (8-pin modular)
Receiver
Intermediate frequency
A band
B Band

38.85MHz/450kHz
46.35MHz/450kHz
Sensitivity (at 12dB SINAD) Less than –15dBμ
Selectivity More than 60dB/55dB (W/N)
Spurious response rejection
A band
B band

More than 60dB/55dB (V/U)
More than 60dB/60dB (V/U)
Audio Output Power More than 2W (10% dist. 8Ω)
External speaker connector 2-conductor 3.5(d) mm 1/8"/4Ω
Receiver sensitivity
FM/FM-N (12dB SINAD)
137–159.995MHz*
375–399.995MHz
500–550.000MHz
160–174.000MHz
400–499.995MHz*

AM/AM-N (10dB S/N)
118–136.991MHz
*Except amateur bands.


–10dBμ
–5dBμ
–5dBμ
–5dBμ
–10dBμ


0dBμ
  • Icom IC-2730A VHF/UHF Dual Band Transceiver
  • HM-207 Hand Microphone
  • OPC-837 Controller Cable
  • Microphone Hanger
  • OPC-345 DC Power Cable
  • Spare Fuses
