PE63

• Resettable circuit breaker
  Easy recovery from overloads; no need to replace a fuse.
• Protection Working Indicator
  SurgeArrest will warn you if its circuitry has been damaged by heavy strike or power line surge and it is unable to provide 100% protection. If still under warranty, APC will then replace your damaged SurgeArrest free of charge.
• Lightning and Surge Protection
  To prevent damage to your equipment from electric power surges and spikes.
• Data-line Protection
  Protection of data lines (Ethernet, Coaxial and Phone lines) ensures complete protection of your equipment from surges. It is very important to protect your equipment from “back door” electric surges traveling through data lines, as they can be as damaging to your equipment as surges traveling over power lines.
• Fail Safe Mode
  Most other surge suppressors continue to let power through even after their circuits have been damaged, leaving your equipment exposed to future surges. APC's SurgeArrest fail safe, which means that once the circuit of an APC SurgeArrest has been compromised the unit disconnects equipment from the power supply ensuring that no damaging surges reach your equipment.

Output:

• Number of Outlets

  6.0

• Receptacle Style

  NEMA 5-15R

Input:

• Nominal Input Voltage

  120V

• Input frequency

  50/60 Hz

• Input Connections

  NEMA 5-15P

• Cord Length

  3ft ( 0.91meters )

• Number of Power Cords

  1

• Input Power

  1200.0Watts

• Maximum Input Current

  15.0A

• Maximum Line Current

  15A

Surge Protection and Filtering:

• Surge energy rating

  540Joules

• ts_nm_surge_response

  1ns

• Peak Current Common Mode

  24kAmps

• Peak Current Normal Mode

  12kAmps

Physical:

• Maximum Height

  1.18inches ( 30mm , 3.0cm )

• Maximum Width

  2.05inches ( 52mm , 5.2cm )

• Maximum Depth

  11.02inches ( 280mm , 28.0cm )

• Net Weight

  0.79lbs. ( 0.36kg )

• Shipping weight

  0.41lbs. ( 0.19kg )

• Shipping Height

  1.26inches ( 32mm , 3.2cm )

• Shipping Width

  3.86inches ( 98mm , 9.8cm )

• Shipping Depth

  12.6inches ( 320mm , 32.0cm )

• Color

  Black , Grey

• Master Carton Dimensions (Length x Width x Height)

  9 x 5 x 13inches ( 229 x 117 x 340mm )

• Master Carton Units

  6.0

• Master Carton Weight

  6.04lbs. ( 2.74 )

• Units per Pallet

  468.0

• SCC Codes

  1073130432882 4

Environmental:

• Operating Environment

  32 - 104 °F ( 0 - 40 °C )

• Operating Relative Humidity

  0 - 95% no %

• Operating Elevation

  0-10000ft ( 0-3000meters )

• Storage Temperature

  -15 - 45 °C

• Storage Relative Humidity

  0 - 95% no %

• Storage Elevation

  0-50000ft ( 0-15000meters )

Conformance:

• Approvals

  MET Canada, MET USA

• Equipment protection policy

  Lifetime : $50000

• Standard warranty

  Lifetime

Sustainable Offer Status:

• RoHS

  Compliant

• REACH

  REACH: Contains No SVHCs
