President Electronics Johnny III AM CB Radio 12V / 24V - TXMU653
SKU:
ZEP-TXMU653
Availability:
Out of stock
No longer available.
Must Have Accessories
Navigating through the elements of the carousel is possible using the tab key. You can skip the carousel or go straight to carousel navigation using the skip links.
Press to skip carousel
Description
Johnny III AM CB Radio 12V/24V - TXMU653
40 channels AM and NOAA Weather channel with Alert
- 40 channels AM - 12V / 24V - Channel rotary switch - Weather Alert - Volume adjustment and ON/OFF - Manual squelch and ASC (Automatic Squelch Control) - Multi-functions LCD display - S-meter - Vox function (Hands free) - ANL filter and HI-CUT - RF Gain - Scan - Priority channel memory - F function key - Beep Function - Roger Beep - Key locking - Front microphone plug - External loudspeaker jack
UPC 3435991725019
President Is Always Ahead In The Future Of CB Radio Technology
PRESIDENT always listens to comments, advice and ideas of its users. We apply these thoughts in new products for a constant process of improvement. This process brings high quality and maximum user satisfaction.
Constant And Maximum Ouput Power Warranty
The output power of the transceiver does not depend on the power supply, due to constant variation. The PRESIDENT units range from 12v to 26.8v. Our output power stays constant and at maximum.
Why Choose A President CB Radio?
Because PRESIDENT invented the Automatic Squelch Control in April 1996.
Because PRESIDENT units are prepared for the 24 volt future revolution in trucks and cars.Very soon 12v will be replaced by 24v.
Because PRESIDENT microphones are totally lightweight for ease of use and durability.
2 Year Warranty
This device is guaranteed 2 years parts and labor in its country of purchase against any manufacturing defects validated by our technical department. PRESIDENT After Sales Service department reserves the right not to apply the warranty in the event a breakdown is caused by an antenna other than those distributed by PRESIDENT.
GROUP PRESIDENT ELECTRONICS is the worldwide market Leader of Citizen’s Band (CB) Radio, bringing millions of CB users together for decades. Starting in 1969 with the creation of the first radio communication company in Paris to 1976 with the first PRESIDENT Branded imported to the US. In 2016 PRESIDENT ELECTRONICS Established US Head Quarters in Naples, FL making President CB Radios available in the North American Continent. In 2021 the First FCC approved AM+FM CB radio in the U.S. and in 2022 First FCC approved portable and mini AM+FM CB radio in the U.S.
The PRESIDENT name is strongly associated with the world of Citizen Band (CB) radios. PRESIDENT is a representative of the Citizen Band in such a way that brings purist CB, HAM/Amateur Radio and technology users around the whole world together. Michael Brigmond President Electronics Brand Manager GigaParts 2/1/2023
Features
Â
General
Number of channels
40
Number of weather channels
7
Weather alert
 YES
Modulation modes
AM
Frequency ranges
from 26.965 MHz to 27.405 MHz
Weather channels
from 162.400 MHz to 162.550 MHz
Antenna impedance
50 ohms
Power supply
13.8 V / 27.6 V
Size (W x D x H)
4.92 in. x 1.77 in. x 5.91 in.
125 mm x 45 mm x 150 mm
Weight
~ 1.54 lbs
~ 0.7 kg
UPC
3435991725019
Accessories supplied
Ultra light electret microphone with support, mounting cradle, screws
Filter
ANL (Automatic Noise Limiter) built-in
Transmission
Frequency allowance
+/- 200 Hz
Carrier power
4 W
Transmission interference
inferior to -60 dBc
Audio response
300 Hz to 3 kHz
Emitted power in the adj. channel
inferior to 20 µW
Microphone sensitivity
3 mV
Drain
1.7 A (with modulation)
Modulated signal distortion
1.80%
Reception
Maxi. sensitivity at 10 dB (S+N)/N
0.6 µV - 111 dBm
Frequency response
300 Hz to 3 kHz
Adjacent channel selectivity
> 60 dB
Maximum audio power
2 W
Squelch sensitivity
minimum 0.2 µV - 120 dBm, maximum 1 mV - 47 dBm
Frequency image rejection rate
60 dB
Intermediate frequency rej. rate
70 dB
Drain
300 mA nominal / 850 mA maximum
Â
Specifications
Â
Power Supply
13.8 V / 27.6 V
Number of channels
40
AM
 YES
Channel selector
rotary
Number of weather channels
7
Weather alert
 YES
Volume
Volume adjustment and ON/OFF
Squelch
Manual squelch
ASC
 YES
Display
LCD multifunction
S-meter
Digital
Public address
 YES
Vox
 YES
Filter ANL
 YES
Filter NB
 YES
Filter HI-CUT
 YES
RF-Gain
 YES
Scan
 YES
Memorie(s)
1
F / Menu function key
 YES
Beep Function
 YES
Roger beep
 YES
Key locking
 YES
microphone plug
front (6 pins)
External Vox microphone jack
 YES
External loudspeaker jack
 YES
Size (W x D x H)
4.92 in. x 1.77 in. x 5.91 in. / 125 mm x 45 mm x 150 mm
Weight
~ 1.54 lbs / ~ 0.7 kg
