Icom IC-T10 VHF/UHF Dual Band FM Transceiver - Rugged, Compact Dual Bander with Simple Opertaion and Great Performance

 Click here for the Icom IC-T10 Brochure

The Icom IC-T10 provides 5W of RF output on 144 and 430 MHz. It boasts 1500 mW loud and intelligble audio. The Icom IC-T10 is IP67 dust-tight and waterproof. It features a home button on the top panel for quick access to the calling channel. The IC-T10 can operate for up to 11 hours with a BP-280 battery.



Other features

DC power operation with optional AD-149H
Free CS-T10 downloadable programming software
Built-in CTCSS/DTCS for repeater operation
Total of 208 memory channels with 6 character channel name
16 DTMF autodial memories
Priority, Program, Memory, Skip, and Tone Scan
Direct-conversion system eliminates IF stages

General
Frequency Coverage USA Version TX 144-148, 430-450MHz (*Working Range)
RX 136-174, 400-479MHz (*Working Range)
FM broadcast 88-108 MHz
Number of channels 208 Channels (Including 2 call and 6 scan edges)
Type of emission F2D, F3E (FM)
Frequency stability ±2.5ppm (-20°C to +60°C on the basic of 25°C)
Power Supply Requirement 7.2V DC nominal
External DC Power 10-16V DC (with AD-149H)
Current Drain (approx) TX High Less than 2.5A
RX Max. Audio Less than 600 mA
Antenna impedance 50Ω (SMA)
Operating temperature range -20°C to +60°C
Dimensions (W x H x D, Projections not included) 2.1 x 4.4 x 1.2 in (with BP-280)
Weight (approximate) 9.8 oz (with BP-280 and antenna)



Transmitter
Output Power 5W, 2.5W, 0.5W
Max. frequency deviation ±5 kHz / ±2.5 kHz (W/N)
Spurious emissions Less than -60 dBc(High, Mid) | Less than -13 dBm (Low)
Ext. microphone connector 3-conductor 2.5(d) mm (1/10")/2.2kΩ



Receiver
Receiver sensitivity Less than 0.18 uV (at 12 dB SINAD)
Squelch sensitivity Less than 0.18 uV (at squelch threshold)
Adjacent channel selectivity More than 55 dB (FM, 25kHz)
More than 50 dB (FM Narrow, 12.5 kHz)
Spurious response More than 60 dB
Audio output power
(at 5% distortion, 8Ω load)
Internal SP 1500 mW (typical)
External SP 450 mW (typical)
HM-222HLWP 1500 mW (typical)
Ext. speaker connector 3-conductor 3.5 (d) mm (1/8")/8Ω

BP-280 Battery Pack

FA-S270C Antenna

MB-133 Belt Clip

BC-213 Rapid Charger

AC Adapter
