Kenwood TM-D750A 144/220/430MHz D-STAR/APRS/FM Triband Transceiver

Kenwood TM-D750A 144/220/430MHz Digital Tribander Mobile Transceiver with GPS & Bluetooth

The Kenwood TM-D750A is a high-performance 144/220/430MHz digital tribander designed for versatile amateur radio communications. Engineered for "The Americas" market, this mobile transceiver combines robust analog performance with advanced digital features including integrated APRS®, D-STAR® support, and a built-in GPS unit supporting the Quasi-Zenith Satellite System. With a vibrant color LCD and simultaneous dual-band reception, it offers unparalleled situational awareness for mobile operators.

Elevate your mobile station with the advanced capabilities of the Kenwood TM-D750A. Whether you are navigating off-road or coordinating emergency communications, this tribander provides the reliability and features you need:

• Powerful Triband Performance: Operates on 144MHz, 220MHz, and 430MHz bands with three-step selectable transmit power (50W/10W/5W) to optimize range and efficiency.
• Advanced Digital Support: Fully compatible with the APRS® data communication system (including Digipeater functions) and D-STAR® digital modes. It supports simultaneous reception of two D-STAR® signals and various D-STAR modes such as Terminal and Reflector modes.
• Integrated Navigation: Features a built-in GPS unit for precise positioning and time synchronization via NTP server communication.
• Modern Connectivity: Includes built-in Bluetooth (SPP, HSP) for wireless flexibility, a microSD card slot (up to 32GB) for data storage, and USB Type-C™ for battery charging and data transfer.
• Visual Monitoring: Stay informed with the Visual Scan and Water Fall Display on the high-quality color LCD, allowing you to monitor signal activity across the band at a glance.
• Dual-Band Reception: Supports simultaneous reception across multiple band combinations (VxU, UxV, UxU, Vx220M, 220MxV, Ux220M, and AIR BAND).

More Information

• APRS Ready: Enjoy real-time two-way data communication with full APRS protocol support. Benefit from a wide range of displays and functions for seamless APRS operations. Built-in KISS TNC provides standalone digipeater functionality, and PC connectivity enables 1200/9600 bps packet and iGate operation.
• D-STAR Compatible: Access the flexible D-STAR network via Bluetooth, USB, or built-in Wireless LAN. Direct Mode simplifies D-STAR networking without external devices. Use Reflector Terminal Mode with the built-in MMDVM command to easily connect to D-STAR reflectors through your PC or Android device.
• Wireless LAN Built-in: Seamlessly connect to D-STAR networks without the need for additional hardware.
• Simultaneous Reception: Monitor two signals at once, expanding your communication possibilities with digital voice and data reception.
• Remote Operation: The included remote operation panel with built-in speaker offers convenient control and audio.
• Integrated GPS: Built-in GPS module and patch antenna provide accurate location information for APRS and other applications.
• Vibrant Display: A large 3.45-inch TFT color LCD with high brightness and wide viewing angles ensures easy readability in any condition.
• Modern Connectivity: USB-C ports and microSD card slots on both the remote head and RF deck provide versatile connectivity options.
• Voice Guidance: Helpful voice prompts with 4-step variable speed and over 900 phrases guide you through operation.
• Superior Audio: Experience renowned Kenwood audio quality through the built-in speaker.

Order your Kenwood TM-D750A today and experience the future of mobile communications!
