Yaesu FT-DX101MP MAX 200W HF/50MHz SDR Transceiver (Includes All Filters)

Comes with the VCT-101, XF-128CN, XF-129CN, XF-128SN, and XF-129SN filters pre-installed.

Honoring the legendary FT-101 while forging the future of HF communication, the Yaesu FT-DX101MP stands as a top-tier HF/50MHz transceiver delivering a robust 200W of output power. Engineered for discerning operators and especially serious contesters, this advanced SDR utilizes a unique hybrid configuration to achieve unparalleled receiver performance in the most challenging DX environments.

The FT-DX101MP combines a high-performance Narrow Band SDR with a Direct Sampling SDR, providing exceptional basic sensitivity and selectivity alongside a stunning Digital Processing Generated Real-Time Spectrum Scope on the vibrant 7-inch color touch panel. This class-leading display features dual multi-function meters and dual frequency readouts, one for each receiver, providing comprehensive operating information at a glance. The innovative 3DSS (3-Dimensional Spectrum Stream) further enhances signal visualization.

Experience superior multi-signal characteristics thanks to the narrowband SDR's crystal roofing filters and a down-conversion receiver design similar to the acclaimed FTDX5000. With phenomenal RMDR (123dB+), BDR (150dB+), and 3rd IMDR (110dB+), the FT-DX101MP excels in rejecting strong adjacent signals. The ultra-low noise local oscillator system, featuring a 400MHz HRDDS, ensures exceptionally quiet and clear reception with a phase noise of -150dBc/Hz at 2kHz separation.

The newly developed VC-TUNE RF Preselector offers an unparalleled -70 dB maximum attenuation for precise signal peaking and effective interference reduction. Its automatic frequency adjustment, driven by a high-precision stepping motor, continuously covers the band for optimal performance.

Designed with the serious operator in mind, the FT-DX101MP features dual LED push-buttons serving as Active Band Indicators for the main and sub receivers, enabling rapid and independent band changes crucial for contesting. The intuitive front panel layout places essential controls like the VFO dial and MPVD (Multi-Purpose VFO Outer Dial) within easy reach, providing versatile control over sub VFO, VC-TUNE, clarifier, and custom functions. Furthermore, the FT-DX101MP offers separate front panel controls for AF and RF gain, Shift, Width, Notch, Contour, Digital Noise Reduction, and APF for both the Main (A) and Sub (B) receivers, providing ultimate flexibility in signal processing.

For added convenience, the FT-DX101MP allows you to display its screen on an external digital monitor.

Key Features:

• High 200W Output Power: Provides commanding signal strength on HF and 6 meters.
• Hybrid SDR Configuration: Combines Narrow Band and Direct Sampling SDR for ultimate performance.
• Exceptional Dual Receiver Performance: Independent control and monitoring of two frequencies.
• Dual Multi-Function Meters and Frequency Readouts: Comprehensive display of operating parameters for both receivers.
• Ultra Low-Noise Local Oscillator (400MHz HRDDS): Ensures quiet and clear reception.
• VC-TUNE RF Preselector (-70 dB Attenuation): Precision signal peaking and effective interference reduction.
• 3DSS (3-Dimensional Spectrum Stream): Intuitive and detailed visualization of signal activity on the 7-inch color touch panel display.
• ABI (Active Band Indicator): Dual illuminated band selection keys for independent control of main and sub receivers.
• MPVD (Multi-Purpose VFO Outer Dial): Versatile control of key operating parameters.
• Comprehensive Interference Reduction Features: Includes effective tools like Contour, Notch, and DNR.
• PC Remote Control (Optional): Enables operation and dual band-scope viewing via LAN or internet (requires optional LAN unit).
• Built-in High-Speed Automatic Antenna Tuner: Ensures efficient antenna matching across bands.
• Dedicated Controls for Main and Sub Receivers: Separate front panel controls for audio, RF gain, and filters.
• External Monitor Output: Allows display on an external screen.

Hybrid SDR Configuration:

The combination of a narrowband SDR, emphasizing fundamental receiver performance, and a direct sampling SDR enables the inclusion of a superb real-time spectrum scope. Optional 300Hz and 1.2kHz roofing filters further enhance the narrowband SDR's capabilities.

Narrow Band SDR Excellence:

Utilizing crystal roofing filters, the narrowband SDR achieves phenomenal multi-signal characteristics. Its down-conversion receiver design, similar to the renowned FTDX5000, features a 9 MHz first IF, a low-noise dual-gate MOS FET, and a D-quad DBM mixer with excellent intermodulation performance. This configuration allows for the use of sharp crystal roofing filters, crucial for exceptional multi-signal reception in challenging interference scenarios. The receiver incorporates Yaesu's legendary RF front-ends, low-noise local oscillators, and carefully selected components, resulting in outstanding proximity BDR, RMDR, and 3rd IMDR values.

Narrow Band SDR + Direct Sampling SDR Synergy:

The narrowband SDR effectively removes strong out-of-band signals, while the direct sampling SDR provides a real-time view of the entire band. The narrowband SDR converts desired signals to digital using a high-resolution 18-bit A/D converter and processes them in an FPGA. This hybrid approach optimizes the entire receiver system. The direct sampling SDR drives the real-time spectrum display, allowing even the weakest signals to be observed, while the narrowband SDR enables precise selection, filtering, and decoding of those signals. The effective roofing filters in the narrowband SDR's front end reduce the signal load on the A/D converter, mitigating interference from strong out-of-band signals, such as powerful AM stations or contest activity.

Truly Quiet and Clear Reception:

The ultra-low noise local oscillator system, featuring a 400MHz HRDDS (High Resolution Direct Digital Synthesizer), is critical for superior proximity multi-signal characteristics. Unlike generic PLLs, this circuit directly divides the high 400 MHz frequency, resulting in a theoretical zero PLL lockup time and eliminating C/N deterioration. This significantly reduces noise throughout the receiver stage and improves BDR in strong signal environments. Combined with carefully selected low-noise components and the latest circuit configurations, the local signal achieves an exceptional phase noise characteristic of -150 dBc/Hz or less at 2kHz separation. This low-noise, high-quality local signal is crucial for excellent multi-signal and ultra-close signal proximity performance.

Unparalleled VC-Tune RF Preselector:

The newly developed VC-Tune RF preselector, driven by a high-precision stepping motor, provides outstanding attenuation characteristics with a maximum attenuation of -70 dB. This automatic frequency adjustment RF preselector continuously covers the band using a variable capacitor, eliminating the steps and switching relays of conventional preset methods. The VC-Tune system stores the last tuning point for each band, allowing for consistent attenuation of recurring interference.

The Highest Transmit Signal Purity:

The 400MHz HRDDS technology also significantly contributes to the transmitter's high signal purity. By meticulously examining every element up to the final TX stage and carefully selecting circuit configurations, Yaesu ensures that the high-quality local signal characteristics are maintained without degradation. The transmit signal is directly generated from a 16-bit D/A converter, bypassing a mixer circuit and significantly suppressing distortion and noise. As a result, the FTDX101 boasts a transmit phase noise characteristic of -150 dBc/Hz at 2kHz separation, delivering the finest performance with a high-purity transmission signal.

New Generation 3DSS Scope Display:

The newly developed 3DSS (3-Dimensional Spectrum Stream) system provides an intuitive way to grasp changes in signal strength, complementing the conventional waterfall display on the 7-inch TFT color touch panel display (800 x 480 pixels).

ABI & MPVD for Superior Operability:

The front panel design emphasizes solid, superior touch and operability. Primary functions like the Main VFO dial, VC-TUNE, and WIDTH/SHIFT are centrally located for easy access. The ABI (Active Band Indicator) keys are positioned above the VFO dial, providing efficient band selection with clear LED indicators for MAIN, SUB, and transmit status. The MPVD (Multi-Purpose VFO Outer Dial), a large aluminum ring around the VFO dial, allows for convenient control of the SUB VFO frequency, VC-TUNE, Clarifier, and custom select functions without taking your hand off the main tuning knob.

PC Remote Control Software:

Optional PC remote control software allows for comfortable operation from a distance via LAN or the internet, taking full advantage of the Hybrid SDR architecture with dual band-scope capabilities and versatile displays. This enables remote transceiver operation, including basic controls, DUAL-BAND scope, and various filter and interference reduction settings.

The Yaesu FT-DX101MP sets a new standard for HF/50MHz transceivers, combining cutting-edge technology with intuitive operation to meet the demands of the most discerning amateur radio operators.

Download the Operating Manual by clicking here.
