Yaesu FT-710 FIELD 100W HF/50MHz Compact SDR Transceiver

SKU
ZYS-FT-710-FIELD
$849.95
Add to Wish List

SAVE $200.00

Regular Price: $1,049.95

$200.00 Instant Rebate (Exp. 03-31-2024)

More on the way

Reserve yours now!
(Ships In 7-14 Days)

Yaesu FT-710 Field HF/50MHz 100W SDR Transceiver

The new FT-710 Field is a compact design yet provides 100W output, utilizing the advanced digital RF technology introduced in the FT-DX101 and FT-DX10 series.

A few of the remarkable features of the new FT-710 Fieldare:

Yaesu unmatched SDR technology emphasizes the receiving performance
Band Pass Filters dedicated for the amateur bands to eliminate out-of-band unwanted signals
RF Front-End design with the 250MHz HRDDS (High Resolution Direct Digital Synthesizer) enables phenomenal multi-signal receiving characteristics
QRM rejection by the dual core 32-bit high speed floating decimal point DSP for SHIFT/WIDTH/NOTCH/CONTOUR/APF/DNR/NB and 3-stage parametric equalizer
High Resolution 4.3 inch TFT color touch panel display
3DSS (3-Dimensional Spectrum Stream)
VMI LED (VFO Mode Indicator) placed around the VFO dial shows the current operating mode (VFO-A, VFO-B, Memory Mode and Clarifier/Split Operation)
"PRESET" Mode Function most suitable for FT8 Operation
AESS: Acoustic Enhanced Speaker System with Optional SP-40 creates the high-fidelity audio output
External Display Connection Terminal (DVI-D)
Built-in High Speed Automatic Antenna Tuner with 100 Channel Memory
Supports the FC-40 Auto Antenna Tuner
SD Memory Card can be used to save the communication record, transceiver setting, the memory contents, screen capture images and to update the firmware
Two (2) USB Ports (Type-A and Type-B)
Other essential features such as CW ZIN and SPOT, IPO (Intercept Point Optimization), and Remote Operation with Network Remote Control System


Purchase your Yaesu FT-710 Field HF/50MHz 100W SDR Transceiver at GigaParts today!

Note: SP-40 Speaker system is purchased seperately

  • HF/50MHz band 100W Compact SDR Transceiver
  • SDR circuit configuration emphasizes Receiving Performance which is enabled by the same high-resolution A/D converter and FPGA used in YAESU high-end SDR transceivers.
  • Powerful RF Front-End and Low Noise Oscillator System enables Phenomenal Multi-Signal Receiving Characteristics*
    • RMDR: 113dB+
    • BDR: 127dB+
    • 3rd IMDR: 102dB+
    • TX Phase Noise: -143dBc/Hz

*Multi-Signal Receiving Characteristic: 14MHz band/2kHz separation

*TX Phase Noise: 100W, CW mode

  • Multi-Pass-Filters dedicated for the amateur bands to eliminate out-of-band unwanted signals
  • Built-in High-Speed Automatic antenna tuner with 100 channel memory
  • Effective QRM rejection afforded by Dual-core 32-bit high speed floating decimal point DSP
  • AESS (Acoustic Enhanced Speaker System) with optional SP-40 speaker to create High-Fidelity audio output
  • High Resolution 4.3-inch TFT Color Touch Panel Display
  • 3DSS, real-time 3D Dimensional Spectrum Stream presentation
  • VMI (VFO Mode Indicator) shows the current operating mode (VFO-A, VFO-B, Memory Mode, and Clarifier/Split operation) at a glance
  • “PRESET” Mode functions most suitable for FT8 operation
  • Equipped with External Display terminal (DVI-D)
  • Two (2) USB Ports (Type-A and Type-B)
  • SD Memory Card Slot
  • Support for FC-40 Auto Antenna Tuner
  • Remote Operation with Network Remote Control System (future feature)
  • Carrying Belt Kit
  • Microphone SSM-75E
  • DC Power Cable with Fuse
  • Spare Fuse
  • Operating Manual
