Yaesu FTX-1F HF/50/144/430MHZ All Mode Field Transceiver Reservation

Yaesu FTX-1F HF/50/144/430MHz All Mode Field Transceiver

The new FTX-1F is a portable transceiver utilizing SDR technology and provides 6W of power output with the 5670mAh Lithium-ion battery pack (Which enables 9-hours stand-alone  operating time on the HF bands, SSB mode, and 8-hours operating time on the V/UHF bands, FM mode based on a 6-6-48 duty cycle). Up to 10W of power output is available when using an external DC power supply.

A number of the fundamental and remarkable features of the new FTX-1F are:

• Operation in SSB, CW, AM, FM and C4FM digital modes
• SDR Technology and 3DSS (3-Dimensional Spectrum Stream) on a 4.3-inch high-resolution full-color touch display panel
• Two independent receiver circuits provide true simultaneous dual-band operation, whether in the same band or in different bands.
  • For example: SSB communication on HF bands simultaneously with C4FM digital communication on V/UHF bands (*HF+V, HF+U, V+V, U+U, V+U, U+V)
• Two Loud speakers ensure clear and powerful audio output
• An optional Automatic Antenna Tuner can be attached to the rear of the transceiver with the 5670mAh high-capacity Li-ion battery pack. The optional Cooling-fan, which is necessary for comfortable FT8 operation, can also be combined with the antenna tuner. (All-in-one rear panel design)
• RF front-end and Low Noise Reference Oscillator, enable Phenomenal Multi-signal Receiving characteristics
• Effective QRM rejection afforded via High-speed 32-bit IF DSP (YAESU’s renowned interference reduction systems: SHIFT / WIDTH / NOTCH / CONTROUR / APF / DNR / NB)
• Compatible with WiRES-X operation
• PMG (Primary Memory Group) function can register and monitor up to 5 frequently used frequencies
• MAG (Memory Auto Grouping) function enables Memory Channels to be categorized in each band that can be quickly recalled by band groups (HF/VHF/UHF/AIR/OTHERS)
• USB ports support CAT operation, audio input/output and TX control

The new FTX-1F will be available early 2025. Please be ready for this forthcoming exciting new radio!

This information and the sample shown at HAM FAIR 2024 are only the preliminary introduction. Detailed information will be announced at a later date.

This radio has not been FCC approved. This listing is not an offer to buy the Yaesu FTX-1F. It is a reservation for your choice to complete the purchase if and when the radio becomes available at a later date.
